POWX1195 APPLICATION .................. 3 DESCRIPTION(FIG.1) ..............3 PACKAGE CONTENT LIST ............. 3 SYMBOLS ..................4 GENERAL POWER TOOL SAFETY WARNINGS ......4 Work area ........................ 4 Electrical safety ....................... 4 Personal safety ....................... 5 Power tool use and care ..................5 Service ........................ - Page 2 POWX1195 DECLARATION OF CONFORMITY ..........11 Copyright © 2016 VARO NV www.varo.com P a g e...
-
Page 3: Application
POWX1195 HAMMER DRILL 1500W POWX1195 1 APPLICATION The machine is intended for hammer drilling in concrete, brick and stone, as well as for light chiseling work. It is also suitable for drilling without impact in wood, metal, ceramic and plastic. -
Page 4: Symbols
POWX1195 4 SYMBOLS In this manual and/or on the machine the following symbols are used: In accordance with essential Read manual before use requirements of the European directive(s) Wear gloves Wear noise protection Class II - The machine is double insulated; Earthing wire Always wear safety goggles is therefore not necessary. -
Page 5: Personal Safety
POWX1195 Personal safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 6: Before Using The Tool For The First Time
POWX1195 When using the electric hammer drill outdoors, connect to the power supply with a type H07RN-F 3G 1.5 mm² extension cable and rain-water-protected plugs in proper working order. Make sure of your footing on ladders and scaffolding when drilling free-handed. -
Page 7: Operation
POWX1195 8 OPERATION Switching ON/OFF Switching on: Press the operating switch (8). Switching off: Release the operating switch(8) Handle attachment (Fig. 2) For reasons of safety, only use the hammer drill with handle attachment. You will be able to obtain a safe body position when working by rotating the handle attachment. -
Page 8: How To Use The Demolition Hammer
POWX1195 How to use the demolition hammer After placing the tip of the tool on concrete surface, switch ON. By utilizing the weight of the machine and by firmly holding the demolition hammer with both hands, one can effectively control the subsequent recoil motion. -
Page 9: Technical Data
POWX1195 11 TECHNICAL DATA Rated Voltage 230 V Rated Frequency 50 Hz Rated Power 1500 W Rotation speed 860 min Protection class Drill capacity concrete 32 mm Drill capacity steel 13 mm Drill capacity wood 42 mm Impact rate 4250 min... -
Page 10: Warranty
We also disclaim all liability for any bodily injury resulting from inappropriate use of the tool. Repairs may only be carried out by an authorised customer service centre for Powerplus tools. You can always obtain more information at the number 00 32 3 292 92 90. - Page 11 VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that, Product : Hammer Drill Trade mark : POWERplus Model : POWX1195 Is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration.
