Seneca Z-UMTS HW2 Installation Manual page 5

TECHNICAL SPECIFICATIONS
POWER SUPPLY
Voltage
Absorption
DIGITAL INPUTS
TOTALIZERS
COUNTERS:
DIGITAL OUTPUTS
ANALOGUE INPUTS
COMMUNICATION
PORTS
3G+ WORLD WIDE
PENTABAND MODEM
SUPPORTED
PROTOCOLS
GNSS
STORAGE UNIT
PROCESSOR
OPERATING SYSTEM
FEATURES
PROCEDURE FOR MODULE SWITCH-OFF
The module is equipped with an integrated UPS that allows it to remain on even in the absence of
external power. To turn off the module, first disconnect the external power supply and then press
the PS1 button on the right side of the module for at least 10 seconds.
When the button is released, the PWR LED turns off to indicate that the module is turned off.
19 – 40 Vdc or 19 – 28 Vac 50 – 60 Hz.
< 6.5W.
Number of channels 4. Configurable PNP or NPN.
Voltage OFF<4V, ON>8V (Max. 24Vdc).
Max frequency 30Hz. Absorbed current 3mA @ 12Vdc 10mA @ 24Vdc.
4 x 32-bit totalizers on non-volatile memory
4 x 32-bit resettable counters on non-volatile memory.
Number of channels 2. SPDT free contact relay.
Max. voltage 250Vac. Max. current 2A.
Number of channels 2. Configurable mAdc or Vdc.
Voltage input 0 – 30V. precision 0.1% of Full Scale, impedance 200 kohm.
Current input 0 - 20mA precision 0.1% of Full Scale, impedance < 60 ohm.
Input protection 40V / 25mA. Resolution 16 bit.
RS485 COM1 on rear IDC10 connector, RS485 or RS232 on terminals
M10-M11-M12, Ethernet 10/100 baseT with autoswitch on front RJ45
socket and USB on microB side socket.
GSM / GPRS / EDGE / WCDMA / HSDPA / HSUPA / HSPA+ / DC-HSPA.
FTP client, SMTP client, http rest (SSL), MQTT (SSL),
ModBUS TCP server, ModBUS TCP client,
ModBUS RTU master, ModBUS RTU slave,
For further information, refer to the User Manual.
8 th generation:
16 GPS channels,
14 GLONASS channels Precision <1.5m CEP-50.
microSD and microSDHC, 32GB max.
ARM 32bit.
Real Time Multitasking
Webserver built-in and on microSD
ENGLISH - 5/8
