Kramer PT-872xr Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
PT-872xr HDMI 4K Line Receiver
1 Power adapter and cord
IMPORTANT NOTICE!
We highly recommend using only Kramer UNIKAT cables with these products. If using 3
shield must be soldered to the connectors for the products to function properly. Do not use any jumpers, unshielded wall plates or mid-
span cable connections. These extenders are not compatible with HDBaseT technologies. Prior to signal extension, ensure that the
extension line cable is lying straight and not coiled.

Step 2: Get to know your PT-872xr

# Feature
1 IN
LED Indicators OUT
2
3 ON
4 HDMI OUT Connector
5 SETUP DIP-switches
6 DGKAT2 IN RJ-45 Connector
7 12V DC Connector
Step 3: Install the
Install PT-872xr using one of the following methods:
•
Attach the rubber feet and place the unit on a flat surface.
•
Fasten a bracket (included) on each side of the unit and attach it to a flat surface
www.kramerav.com/downloads/PT-872xr
(see
•
Mount the unit in a rack using the recommended rack adapter
www.kramerav.com/product/PT-872xr
(see
PT-872xr Quick Start
PT-872xr Quick Start Guide
This guide helps you install and use your PT-872xr for the first time.
Go to www.kramerav.com/downloads/PT-872xr
upgrades are available.
4 Rubber feet
1 Bracket set
Function
Lights when an active source is connected to HDMI IN on the PT-872xr.
Lights when an active acceptor is connected to HDMI OUT on the .
Lights when power is connected to the device.
Connect to an HDMI acceptor.
Set the operation DIP-switches. Both DIP-switches are set to OFF (up) by default.
Always set the DIP-switches identically on transmitter and receiver devices.
DIP-switch 1:
Compression Options
DIP-switch 2:
Compression Setup
Connect to the DGKat-2.0 OUT connector on the
Connect the power adapter to the device.
).
).
to download the latest user manual and check if firmware
1 Quick start guide
rd
party shielded CAT-6A cables, both ends of the
OFF (up) – Standard compression level.
ON (down) – High compression level for additional range extension.
OFF (up) – Enable compression (mandatory).
ON (down) – For future use.
WP-871xr
• Ensure that the environment (e.g., maximum ambient temperature &
air flow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
P/N: 2 9 0 0 - 3 0 1 0 0 5 QS
using twisted pair cable.
Rev: 2
