Advantech USB-5817 Startup Manual

USB-5817
8-Channel,16-Bit, 200 kS/s USB 3.0 Isolated
Analog Input Module
Startup Manual
Packing List
Before installation, please ensure that the following items
are included with the product:
1. 1 x USB-5817 module
2. 4 x Terminal blocks
3. 1 x Startup manual
4. 1 x USB 3.0 lockable cable (1 m)
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
User Manual
For more detailed information regarding this product, please
download the USB-5817 user manual from the Advantech
website.
Overview
Advantech's USB-5817 is an industrial USB 3.0 isolated
analog input module. To ensure easy installation in cabinet
computers, USB-5817 modules are compact and equipped
with a DIN rail mount kit. The built-in USB hub can support
a daisy-chain topology, while Euro-type pluggable terminal
blocks and LED indicators facilitate configuration and
maintenance.
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
For driver/SDK downloads and technical support
services, please visit our support website at
http://support.advantech.com
This manual is for USB-5817.
Part No. 2041581700
Printed in China
Specifications
General
• Connectors:
• Dimensions:
• Operating Temperature: 0 ~ 60 °C (32 ~ 140 °F)
• Storage Temperature: -40 ~ 70 °C (-40 ~ 158 °F)
• Storage Humidity: 5 ~ 95% RH (non-condensing)
• Power Supply: 10 ~ 30 V
• Interface: USB 3.0
• Data Transfer Rates: 5 Gbps
• Power Consumption:
• ESD Protection
• DC Surge Protection: 2 kV
Analog Input
• Number of Input Channels: 8 differential, can be en-
• A/D Converter (ADC) Resolution: 16 bits (15 bits for
• A/D Converter (ADC) Type: Successive approximation
• Maximum Sample Rates (fs): 200 kS/s shared by all
• Input Coupling: DC
• Input Range: ±10 V, 0 ~ 20 mA
• Input Common-Mode Voltage Range: ±275 V
• Absolute Accuracy
• Temperature Drift
• Bandwidth (-3dB): 10 kHz
• Idle Channel Noise: 0.27 mV
• Signal-to-Noise Ratio (SNR): 87 dB
• Total Harmonic Distortion (THD) : -98 dB
• Total Harmonic Distortion Plus Noise (THD+N): -87 dB
• Spurious-Free Dynamic Range (SFDR): 102 dB
• Effective Number of Bits (ENOB): 14.2 bits
Edition 1
January 2019
- 2 x 10-pin terminal block (3.81 mm, AI)
- 2 x 3-pin screw terminal block (3.81 mm, power)
- USB 3.0 type A (downstream port)
- USB 3.0 type B (upstream port)
120 x 120 x 40 mm (4.72 x 4.72 x 1.57 in
3
- Using USB bus power: 350 mA typical @ 5 V
- Using external power: 100 mA typical @ 24 V
- Air: ±8 kV
- Contact: ±6 kV
abled/disabled independently using software
current measurement)
(SAR)
channels
- Offset Error: < ±1 mV
- Gain Error: < ±0.01% of full-scale range
- Offset Drift: 25 ppm/°C
- Gain Drift: 15 ppm/°C
tion)
USB-5817 Startup Manual 1
)
3
DC
(16 bits effective resolu-
RMS
