Advantech USB-582 Startup Manual

USB-5820
4-Channel, 16-Bit, 200 kS/s Isolated Analog
Output USB 3.0 I/O Module
Startup Manual
Packing List
Before installation, please ensure that the following items
are included with the product:
1. 1 x USB-5820 module
2. 3 x Terminal blocks
3. 1 x USB-5820 startup manual
4. 1 x USB 3.0 lockable cable (1 m)
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
User Manual
For more detailed information regarding this product, please
download the USB-5820 user manual from the Advantech
website.
Overview
Advantech's USB-5820 is an industrial-grade isolated ana-
log output USB 3.0 I/O module. To ensure easy installation
in cabinet computers, USB-5820 modules are compact and
equipped with a DIN-rail mount kit. The built-in USB hub can
support a daisy-chain topology, while Euro-type pluggable
terminal blocks and LED indicators can facilitate configura-
tion and maintenance.
For more information about this or other Advantech
products, visit our website at
http://www.advantech.com
For driver/SDK downloads and technical support
services, visit our support website at
http://support.advantech.com
This manual is for USB-5820.
Part No. 2041582000
Printed in China
Specifications
General
• Connectors:
1 x 10-pin terminal block (3.81 mm, A/O)
2 x 3-pin screw terminal blocks (3.81 mm, power)
1 x USB 3.0 type A (downstream port)
1 x USB 3.0 type B (upstream port)
• Dimensions:
120 x 120 x 40 mm
• Operating Temperature: 0 ~ 60 °C (32 ~ 140 °F)
• Storage Temperature: -40 ~ 70 °C (-40 ~ 158 °F)
• Storage Humidity: 5 ~ 95% RH (non-condensing)
• Power Supply: 10 ~ 30 V
• Interface: USB 3.0
• Data Transfer Rates: 5 Gbps
• Power Consumption:
100 mA typ./130 mA max. @24 V external power
450 mA typ./770 mA max. @5 V bus power
• ESD Protection:
Air: ±8 kV
Contact: ±6 kV
• DC Surge Protection: 2 kV
Analog Output
• Channels: 4
• Resolution: 16 bits
• Output Voltage Range: 0 ~ 5 V, 0 ~ 10 V, ±5 V, ±10 V
• Output Current Range:
0 ~ 20 mA, 4 ~ 20 mA (source type)
• Load:
> 1 kΩ (voltage output)
< 625 Ω (current output)
• Output Error: < ±0.1% of full-scale range
• Isolation Protection: 2,500 V
• Updating Rate:
200/n kS/s, where n is the number of enabled channels
(n = 1 ~ 4)
• Slew Rate: 1 V/µs
Installation Instructions
1. Install the SDK and drivers downloaded from the
Advantech website.
2. Touch the metal case of the computer to discharge any
static electricity that may be in your body.
3. Insert the USB module into the designated USB port.
Use caution when inserting the module to avoid damag-
ing the components due to excessive force.
Edition 1
April 2019
(4.72 x 4.72 x 1.57 in )
3 3
DC
DC
USB-5820 Startup Manual 1
