- Page 2 Connect brown cable wire of new scanner to the same terminal on the line box to which the original brown lead was attached. Skip one terminal and connect the extended red lead to the terminal where the orange lead of the old scanner was removed. Connect shielded leads to recovery amplifier boards.
