    Overview This manual contains all of the Code Blue PAS information needed on the CB 1 series with Public Address, CB 5-s with Public Address, WM-180 Public Address System, CB 2-e with Public Address and 360...
  • Page 5 WM-180 to be directly man- aged by Code Blue’s Blue Alert® MNS (Mass Notification System) software, granting the user messaging options. The controller also monitors the amplifier and speaker for various failures, which are reported to the appropriate maintenance personnel, and...

  • Page 6: Before You Start

    Department of Defense’s antiterrorism requirements. Implement national design standards and recommendations for mass notification systems, as provided in NFPA 72, including Annex 2.3 Precautions Code Blue recommends professional services before the order and installation of all PAS products. For survey information, please email customerservice@codeblue.com.
  • Page 7 If the unit emits smoke or an unusual smell, water or other foreign materials enter the enclosure, or the unit is dropped or the enclosure is damaged, power off immediately and contact Code Blue Customer Service. Email: customerservice@codeblue.com Toll free: 800-205-7186, Opt. 2 Code Blue ● ● ● ● ●...

  • Page 8: How To Update Connectors

    Administrator Guide 3 How to Update Connectors As of 2020, many Code Blue products come with Wago connectors. These connectors provide ease of use and a much stronger connection. Below are the steps needed to change to the new connectors.
  • Page 9 Repeat on the rest of the connectors. Once all connectors have been switched, you are ready to apply power. Please contact technicalsupport@codeblue.com if you need further assistance. Code Blue ● ● ● ● ● 259 Hedcor Street...

  • Page 10: Installation & System Setup

    4.1.3.2 Place the adapter ring on top of the bollard and tighten the three Allen set screws to hold in place (see Figure 2 on Page 12). Code Blue ● ● ● ● ● 259 Hedcor Street...
  • Page 11 7 pin control cable and RJ-11 to the phone board. Connect the large white connector of the amplifier wiring harness to the wiring connector on the transformer. Refer to the included wiring diagram for wiring terminations (See Figure 1 on Page 10). Code Blue ● ● ● ●...
  • Page 12 4.1.5.3 Set the PAS speaker unit on the adapter ring, lining up the screw holes at the bottom of the unit. Secure the speaker unit with the provided security screws. Code Blue ● ● ●...
  • Page 13 Public Address System Administrator Guide 4.1.5.4 Reapply power to the unit (see Error! Reference source not found. on Page Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 13 of 31...
  • Page 14 Set the PAS speaker unit on the adapter ring, lining up the screw holes at the bottom of the unit. Secure the speaker unit with the provided security screws. 4.2.4.4 Reapply power to the unit (See Figure 7 on Page 21). Code Blue ● ● ●...
  • Page 15 Public Address System Administrator Guide Figure 2 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 15 of 31 GU-153-G...
  • Page 16 “Line” and “Neutral.” 120/240V AC supply – Using the proper crimping tool, attach a #8 fork to each 4.3.3.3 of the incoming power wires and fasten them to the correct terminals as labeled on the Code Blue ● ● ● ●...
  • Page 17 Figure on Page 23). 4.3.4 Communications Wiring 4.3.4.1 Have category 3 or higher 4 pair cable terminated to a RJ45 applying TIA/EIA T568-B specifications. Figure 3 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186...
  • Page 18 Reference IA4100 Admin and User Guide for analog controller board programming. 4.5.1.4 Reference IP5000 Admin and User Guide for IP controller board programming. 4.5.1.5 Code Blue guides are located at codeblue.com > support > downloads. 4.6 Installation without Controller Board 4.6.1.1 Supply 24V AC to Power Manifold. 4.6.1.2 See attached wiring diagram for connecting the PAS Audio Cable and PAS Control Cable to the nearby IA4100 or IP5000 speakerphone.
  • Page 19 Public Address System Administrator Guide 4.6.1.5 Code Blue guides are located at codeblue.com > support > downloads. Figure 4 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 19 of 31...

  • Page 20: Software Configuration

    Once settings are complete, simply “Click to Program,” or select assorted units and choose “Program All Units” to apply operational parameters. The Diagnostic section of the software package is capable of testing all on-site Code Blue units for functionality at any specified time daily, weekly or on a specified day and time. This flexibility tailors testing at predetermined intervals to confirm the phones are working 24/7.
  • Page 21 Immediate fault reporting via multiple email addresses guarantees minimum response time to any operational issues. Route an email to an SMS server and your on-call technician receives a text on their cell phone for immediate deployment, ensuring maximum up time of your units. Code Blue ● ●...

  • Page 22: Architectural Overview

    Public Address System Administrator Guide 6 Architectural Overview Figure 5 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 22 of 31 GU-153-G...

  • Page 23: Wiring Diagrams

    Public Address System Administrator Guide 7 Wiring Diagrams WM-180 PAS Controller wiring diagram Figure 6 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 23 of 31 GU-153-G...
  • Page 24 Public Address System Administrator Guide 7.2 CB 2-e with Public Address Wiring Diagram Figure 7 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 24 of 31 GU-153-G...
  • Page 25 Public Address System Administrator Guide CB 1 Series and CB 5-s with Public Address and 360 Retrofit Wiring Diagram 1 7.3.1 PAS 1 Generation 2 Rev. 1 Figure 8 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186...
  • Page 26 Public Address System Administrator Guide 7.4 CB 1 Series and CB 5-s with Public Address and 360 Retrofit Wiring Diagram 2 7.4.1 PAS Generation 2 Rev. 2 Figure 9 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186...
  • Page 27 Public Address System Administrator Guide 7.5 Detailed PAS 1 Power Schematic Figure 10 Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018 page 27 of 31 GU-153-G...

  • Page 28: Troubleshooting

    Public Address System Administrator Guide 8 Troubleshooting General Issues Please contact Code Blue Technical Support if you do not see your issue below. 8.1.1 PAS not working 8.1.1.1 Remove the control cable from the amp. This will turn the amp on at all times. Try a new test call.
  • Page 29 Public Address System Administrator Guide Advanced Issues 8.1.5 8.1.5.1 For advanced trouble shooting, please email techsupport@codeblue.com or call 800- 205-7186, Opt. 3. Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com Rev 12/2018...

  • Page 30: Spare Parts

    9.3 WM-180° PAS Wall Mount Part Number Part Description Notes 40009 Amp Assembly Contains amp and amp harness, if needed 40101 5-Finger Manifold Contains manifold and 5 amp fuse Code Blue ● ● ● ● ● 259 Hedcor Street Holland, MI 4923 USA 800.205.7186 www.codeblue.com...

  • Page 31: 0 Download Information

    Public Address System Administrator Guide 1 0 Download Information Code Blue now has a centralized location where you can find installation, setup, information, configuration and operation instructions. ® 1. Centry Administrator Guide: www.codeblue.com/resources/guides 2. CB 1 Series Administrator Guide: www.codeblue.com/resources/guides 3.
