  • Page 1 CB 2 Series Installation | Confi guration | Operation | Troubleshooting Administrator Guide 800.205.7186 www.codeblue.com •...
  • Page 2 OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Code Blue Corporation reserves the right to make any modifications to this guide or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.

  • Page 3: Table Of Contents

    20 CB 2-s Installation Instructions.............38 21 Pole Mount Bracket Installation Instructions.......41 22 AED Access and Maintenance Guide..........42 23 CB 2 Series Remote Mount Beacon/Strobe Installation....43 24 S-1000/S-1050/S-2000 Installation Instructions......44 25 CB 2-a Standard Wiring Diagram...........46 26 CB 2-a PoE Diagram...............47 27 Legacy CB 2-a Standard Wiring Diagram ....48...
  • Page 4 Administrator Guide 32 CB 2 24V or Multi-Tap Power Brick Wiring ....53 (prior to 2020) 33 CB 2 Series Standard Wiring ..54 (prior to 3/2013) (with Hammond Transformer) 34 Legacy Cb 2-e with Public Address Wiring Diagram....55 35 Legacy CB 2-e with AED Housing Wiring Diagram.....56 36 CB 2-s Wiring Diagram..............57...

  • Page 5: Introduction

    CB 2 Series Administrator Guide 2 Introduction The 2 Series Wall Mount Help Points ® This popular line is a good fi t for any indoor or outdoor application, including parking facilities. Our unmistakable craftsmanship makes our Help Points the most rugged on the market, withstanding ®...

  • Page 6: Getting Started

    1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper operation of Code Blue communication devices connected to copper or fiber infrastructures. Communications cable and electrical cable in the same conduit is not an acceptable instal- lation and shall not be supported.

  • Page 7: Spare Parts

    CB 2 Series Administrator Guide 4 Spare Parts CB 2-a & CB 2-e (2020) Part Part Number S-2000 LED Strobe Light 41162 Analog Phone Line Surge Suppressor 41471 IP Phone Line Surge Suppressor 41421 DIN Rail Assy 40110 PoE Switch...
  • Page 8 IP Phone Line Surge Suppressor 41421 Manifold R/B 5-way 40101 Power Brick 120V, 240V & 277V 40104 LED Area Light 41539 CB 2 Series Additional Options Quantity Part Description Document packet (Installation and Setup) Hardware packet Lag screw sleeves Metal washers Rubber washers...

  • Page 9: Power Requirements

    CB 2 Series Administrator Guide 5 Power Requirements (2020) (The following power requirements include the 2 Series and also ALL OTHER Code Blue units.) Component Specs Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High V IA4100 24V AC 0.40...
  • Page 10 0.22 S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13 12V DC 2.68 32.16 0.38 4.56 0.11 CB 2 Series 24V DC 2.68 64.32 0.38 9.12 0.22 LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02 12V DC 0.04...
  • Page 11 ® CB 4-u w/ NightCharge 0.22 120V AC 0.13 0.11 CB 2 Series 0.22 0.02 0.01 0.02 Administrator Guide 1.21 Power Requirements continued Models With IP5000 Faceplate Voltage Current Watts KWHrs CB 1-e 24V AC 0.33 7.92 0.19 12V DC 0.43...

  • Page 12: Legacy Power Requirements

    CB 2 Series Administrator Guide 6 Legacy Power Requirements (The following power requirements include the 2 Series and also ALL OTHER Code Blue units.) Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 12 of 63 GU-149-AA •...
  • Page 13 CB 2 Series Administrator Guide Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 13 of 63 GU-149-AA • • • •...

  • Page 14: Software Configuration

    A sophisticated emergency management platform for your blue light phone network, ToolVox offers unique real-time monitoring and provisioning options for emergency phones and public address speakers, effectively acting as a hub for connecting Help Points and other Code Blue devices. Us- ® ing our proprietary incident response software, Blue Alert MNS and EMS, you can send alerts via ®...

  • Page 15: Cb 2-A Exploded View

    CB 2 Series Administrator Guide 8 CB 2-a Exploded View ITEM # DESCRIPTION Wall Mount Shell Assy 2 Series Wall Plate Assy LED Faceplate Light LED Blue Beacon Strobe Standard / Custom Graphic DIN Rail Assy 28” Harness, 4 Connector 28”...

  • Page 16: Cb 2-E Exploded View

    CB 2 Series Administrator Guide 9 CB 2-e Exploded View ITEM # DESCRIPTION Wall Mount Shell Assy 2 Series Wall Plate Assy LED Blue Beacon Strobe Standard / Custom Graphic DIN Rail Assy 28” Harness, 4 Connector 28” Harness, 1 Connector...

  • Page 17: Legacy Cb 2-E Low Voltage Exploded View

    CB 2 Series Administrator Guide 10 Legacy CB 2-e Low Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION 41425 HID Lens 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP...

  • Page 18: Legacy Cb 2-E High Voltage Exploded View

    CB 2 Series Administrator Guide 11 Legacy CB 2-e High Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION 41425 HID Lens 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP 40159 LED Beacon Strobe 50102 Double Button IP5000 VoIP Phone –...

  • Page 19: Cb 2-S Low Voltage Exploded View

    CB 2 Series Administrator Guide 12 CB 2-s Low Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP 50105 Double Button IP5000 VoIP Phone – EMERGENCY 40407 Bezel Assembly IA4100 Analog Phone –...

  • Page 20: Cb 2-S High Voltage Exploded View

    CB 2 Series Administrator Guide 13 CB 2-s High Voltage Exploded View BALL # PART # DESCRIPTION BALL # PART # DESCRIPTION 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP 50105 Double Button IP5000 VoIP Phone – EMERGENCY 40407 Bezel Assembly IA4100 Analog Phone –...

  • Page 21: How To Replace Led Light Connectors

    Administrator Guide 14 How to Replace LED Light Connectors As of 2020, Code Blue strobe, area and faceplate lights come with Wago connectors. These con- nectors provide ease of use and a much stronger connection. Below are the steps needed to change to the new connectors.
  • Page 22 CB 2 Series Administrator Guide Strip all wires and twist tight. Place small screwdriver into square hole and push down. Insert cut wire into round hole and remove screwdriver. Repeat on the rest of the connectors. Once all connectors have been switched, you are ready to apply power to the LED.

  • Page 23: Cb 2-A Installation Instructions

    Please inform Code Blue Corporation of any inaccuracies or omis- power supply used with this product shall fulfill the requirements for sions. Code Blue cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the Safety Extra Low Voltage (SELV) and Limited Power Source (LPS) according to IEC/EN/UL 60950-1.
  • Page 24 CB 2 Series Administrator Guide Tools needed for installation: 1. Drill 2. Drill bit (5/8” Masonry bit for concrete; 1/2” standard bit for wood) 3. 3/8” Hex head driver bit 4. Level Basic installation instructions: 1. Unscrew security screw from bottom of unit. Lift and open unit.
  • Page 25 CB 2 Series Administrator Guide Mounting Schematics 9.00 28.21 1.25 26.00 2.21 Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 25 of 63 GU-149-AA • • • •...

  • Page 26: Cb 2-E Installation Instructions

    Please inform Code Blue Corporation of any inaccuracies or omis- power supply used with this product shall fulfill the requirements for sions. Code Blue cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the Safety Extra Low Voltage (SELV) and Limited Power Source (LPS) according to IEC/EN/UL 60950-1.
  • Page 27 CB 2 Series Administrator Guide Tools needed for installation: 1. Drill 2. Drill bit (5/8” Masonry bit for concrete; 1/2” standard bit for wood) 3. 3/8” Hex head driver bit 4. Level Basic installation instructions: 21. Unscrew security screw from bottom of unit. Lift and open unit.
  • Page 28 CB 2 Series Administrator Guide Mounting Schematics 9.00 28.21 1.25 26.00 2.21 Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 28 of 63 GU-149-AA • • • •...

  • Page 29: Legacy Cb 2-E Installation Instructions

    CB 2 Series Administrator Guide 17 Legacy CB 2-e Installation Instructions 1.0 PRE-INSTALLATION 1.1 Electrical preparation – The unit may have supply wires run from either (a) behind the unit through the wall, or (b) below the unit using an external conduit through the bottom of the unit.
  • Page 30 CB 2 Series Administrator Guide Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 30 of 63 GU-149-AA • • • •...
  • Page 31 CB 2 Series Administrator Guide Suggested installation dimensions shown from ground to lower right mounting hole are for single button face- plates. • For dual button faceplate, deduct 3.25 inches. • For keypad faceplate, deduct 4.5 inches. • For wheelchair direct facing access only, deduct 6 inches.

  • Page 32: Legacy Cb 2-E With Public Address Installation Instructions

    CB 2 Series Administrator Guide 18 Legacy CB 2-e with Public Address Installation Instructions 1.0 PRE-INSTALLATION 1.1 Electrical preparation – The unit may have supply wires run from either (a) behind the unit through the wall, or (b) below the unit using an external conduit through the bottom of the unit.
  • Page 33 CB 2 Series Administrator Guide Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 33 of 63 GU-149-AA • • • •...
  • Page 34 CB 2 Series Administrator Guide Suggested installation dimensions shown from ground to lower right mounting hole are for single button face- plates. • For dual button faceplate, deduct 3.25 inches. • For keypad faceplate, deduct 4.5 inches. • For wheelchair direct facing access only, deduct 6 inches.

  • Page 35: Legacy Cb 2-E With Aed Housing Installation Instructions

    CB 2 Series Administrator Guide 19 Legacy CB 2-e with AED Housing Installation Instructions 1.0 PRE-INSTALLATION 1.1 Electrical preparation – The unit may have supply wires run from either (a) behind the unit through the wall, or (b) below the unit using an external conduit through the bottom of the unit.
  • Page 36 CB 2 Series Administrator Guide 12.53 8.00 36.00 46.72 21.00 23.06 3.00 9.00 15.5 Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 36 of 63 GU-149-AA • • • •...
  • Page 37 CB 2 Series Administrator Guide Ø .44 MOUNTING HOLES 4 PLCS 45.22 36.00 Ø 1.13 KNOCKOUTS FOR Ø 3/4 CONDUIT 8.00 2 PLCS 21.00 3.00 BOTTOM 9.00 12.40 28.00 GROUND LEVEL 2.20 8.00 MOUNTING SURFACE 1.62 Ø 1.13 THRU BOTTOM PLATE FOR Ø...

  • Page 38: Cb 2-S Installation Instructions

    CB 2 Series Administrator Guide 20 CB 2-s Installation Instructions 1.0 PRE-INSTALLATION 1.1 Running the wires – Wires to the unit may be run either (a) from behind the unit through the wall, or (b) from below the unit using an external conduit through the bottom of the unit’s back plate.
  • Page 39 CB 2 Series Administrator Guide Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 39 of 63 GU-149-AA • • • •...
  • Page 40 CB 2 Series Administrator Guide 12 REF 12 REF 4 X Ø7/16 MOUNTING HOLES 4 X Ø7/16 MOUNTING HOLES 30 3/4 30 3/4 42 REF 42 REF 2 X Ø1-1/8 2 X Ø1-1/8 (KNOCKOUTS FOR (KNOCKOUTS FOR Ø3/4 CONDUIT) Ø3/4 CONDUIT)

  • Page 41: Pole Mount Bracket Installation Instructions

    CB 2 Series Administrator Guide 21 Pole Mount Bracket Installation Instructions 1.0 THREAD MOUNTING STRAPS THROUGH SLOTS Code Blue 1.1 Thread mounting straps through slots for any size poles. ® ® CB 2-e 2.0 HOLD BRACKET TO POLE Pole Mount Instructions 2.1 Set the height of the bracket (C) so that the speakerphone push button(s) on the unit will be...

  • Page 42: Aed Access And Maintenance Guide

    Additional AED Housing key fobs are available under Part #41107. Each Code Blue unit can sync up to 40 different fobs. If a new user key fob is added, then the rule is “fi rst in, fi rst out”. For example, No. 41 will push out the fi rst user of the system.

  • Page 43: Cb 2 Series Remote Mount Beacon/Strobe Installation

    CB 2 Series Administrator Guide 23 CB 2 Series Remote Mount Beacon/Strobe Installation ATTACH J-BOX TO THE POLE Thread the banding (B) through the pole bracket (A) located on the backside of the J-box (C). Wrap the banding around the pole. Cut the banding to desired length.

  • Page 44: 1000/S-1050/S-2000 Installation Instructions

    CB 2 Series Administrator Guide 24 S-1000/S-1050/S-2000 Installation Instructions S-2000 (for CB 2-a & CB 2-e ONLY) POSITIVE (12-24V DC or AC) BLACK COMMON (GROUND) YELLOW (FLASH MODE) S-1000 YELLOW (FLASH MODE) DRY CONTACT POSITIVE (12-24V DC or AC) CLOSED = "ON"...
  • Page 45 CB 2 Series Administrator Guide PROGRAMMING PRIMARY & SECONDARY MODES 1. Remove power from unit. 2. Short the Yellow wires together. 3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short.

  • Page 46: Cb 2-A Standard Wiring Diagram

    CB 2 Series Administrator Guide 25 CB 2-a Standard Wiring (2020) Beacon Strobe Faceplate LED Bar For Incoming Power 24V AC/DC or 100-277V AC For High Voltage leave connected. To Ground IP5000 For Low Voltage RJ45/RJ11 disconnect and apply incoming power.

  • Page 47: Cb 2-A Poe Diagram

    CB 2 Series Administrator Guide 26 CB 2-a PoE Wiring (2020) Beacon Strobe Faceplate LED Bar For Incoming Power Centry Incoming POE IP5000 Ground Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.

  • Page 48: (Prior To 2020)

    CB 2 Series Administrator Guide 27 Legacy CB 2-a Wiring Diagram (prior to 2020) S-180-1224-LED Neutral Load 100 – 240Vac / 0.5A High Voltage 277Vac /0.2A Power 12Vdc 3.3A Option Class 2 FP-LED Bar IP5000 VoIP Main 12VDC or LAN 1...

  • Page 49: Legacy Cb 2-A Standard Wiring Diagram

    CB 2 Series Administrator Guide 28 CB 2-e Standard Wiring (2020) Beacon Strobe Faceplate LED Bar For Incoming Power 24V AC/DC or 100-277V AC For High Voltage leave connected. To Ground IP5000 For Low Voltage RJ45/RJ11 disconnect and apply incoming power.

  • Page 50: Cb 2-E Poe Diagram

    CB 2 Series Administrator Guide 29 CB 2-e PoE Wiring (2020) Beacon Strobe Faceplate LED Bar For Incoming Power Centry Incoming POE IP5000 Ground Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.

  • Page 51: (With Triad Transformer)

    CB 2 Series Administrator Guide 30 CB 2-e 120V Standard Wiring (2015-2020) (with Triad Transformer) Lighting Units Beacon Strobe 12 – 24 Volts AC or DC IA4100 LED Faceplate light 12 – 24 Volts AC or DC Output Audio Strobe...

  • Page 52: Legacy Poe Installation Instructions

    12V DC switch position favors the DATA – PoE+ side of the module First: Electrical connections, All 4 Customer Code Blue devices should to be Cat5e connected to the 5 place manifold DATA DATA – PoE+ Second: Manifold fused red lead...

  • Page 53: (Prior To 2020)

    CB 2 Series Administrator Guide 32 CB 2 Series 24V or 120V Multi-Tap Power Brick Wiring (prior to 2020) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.

  • Page 54: Cb 2 Series Standard Wiring

    CB 2 Series Administrator Guide 33 CB 2 Series 120V Standard Wiring (prior to 03/2013) (with Hammond Transformer) (with Hammond Transformer) Product wiring diagram shown reasonably represents current offering and is intended to assist in component identifi cation and service. Earlier product production may have different components and wiring connections.

  • Page 55: Legacy Cb 2-E With Public Address Wiring Diagram

    CB 2 Series Administrator Guide 34 Legacy CB 2-e with Public Address Wiring Diagram POWER SUPPLY LIGHTING Beacon/Strobe MULTI-TAP 12-24V AC or DC • Multi-Tap LV fuses are generally 2A GMA Faceplate Light 12-24V AC 12V DC or DC 24V AC...

  • Page 56: Legacy Cb 2-E With Aed Housing Wiring Diagram

    CB 2 Series Administrator Guide 35 Legacy CB 2-e with AED Housing Wiring Diagram Product wiring diagram shown reasonably represents current offering and is intended to assist in component identification and service. Earlier product produc- tion may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact the manufacturer to confirm replacement part version and availability.

  • Page 57: Cb 2-S Wiring Diagram

    CB 2 Series Administrator Guide 36 CB 2-s Wiring Diagram POWER SUPPLY LIGHTING Beacon/Strobe MULTI-TAP 12-24V AC or DC • Multi-Tap LV fuses are generally 2A GMA Faceplate Light 12-24V AC 12V DC or DC 24V AC 120V, 240V, 277V,...

  • Page 58: Multi-Tap Transformer Wiring

    CB 2 Series Administrator Guide 37 Multi-Tap Transformer Wiring Side of the Incoming Power from Primary Side of the Secondar Supplier Transformer Transformer Neutral Source L1 (White) Primary Volt Amps 250 Secondar olt Amps 160 ETL – UL ______________ Source L2 (Black)

  • Page 59: Maintenance Schedule

    CB 2 Series Administrator Guide 38 Maintenance Schedule LEGEND Guard tasks Technician tasks DAILY OR WEEKLY Perform functional communications check Action: Press red button Strobe activates  Red LED “Call Placed” light turns on  Message plays  Call connects, green LED “Call Received” light turns on ...
  • Page 60 Administrator Guide UNIT SURFACE MAINTENANCE The painted and stainless steel Code Blue models require periodic care to sustain their aesthetic appearance. Units located outdoors are vulnerable to harsh environmental conditions, including UV rays, acid rain, diesel fumes and airborn iron particles (i.e., dust) which over time may cause unit discoloring.

  • Page 61: Locating Unit Serial Numbers

    CB 2 Series Administrator Guide 39 Locating Unit Serial Numbers Remove the speakerphone faceplate with the special security bit. The serial number will be listed on the manufacturer’s label located inside the unit (1). Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186...

  • Page 62: Warranty

    Administrator Guide 40 Warranty Code Blue Corporation provides a limited warranty on this product. Refer to your sales agreement to establish the terms. In addition, Code Blue’s standard warranty language, as well as information regarding support for this product while under warranty, is available at www.codeblue.com/support.

  • Page 63: Download Information

    CB 2 Series Administrator Guide Download Information 41 Download Information Code Blue now has a centralized location where you can find installation, setup, information, configuration and operation instructions. ® 1. Centry Administrator Guide: www.codeblue.com/resources/guides 2. CB 1 Series Administrator Guide: www.codeblue.com/resources/guides...
