Si04-753
3. Removal of Horizontal Blades / Vertical Blades
Procedure
Step
1. Remove the horizontal
blades.
1
Open the horizontal
blades.
Release the left shaft of
2
the horizontal blades.
Bend the horizontal
3
blades slightly and
release the center
shaft.
Slide the horizontal
blades to the left and
release the right shaft.
Removal Procedure
Warning
Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Procedure
Horizontal blades
Left shaft
Removal of Horizontal Blades / Vertical Blades
(R2763)
(R2764)
Center shaft
(R2765)
1. Since the key pattern hook is
2. Fit the blade to the center
Right shaft
(R2766)
Points
Installation procedure
provided, rotate the blade
and fit it to the right shaft
first.
and left shafts.
7
