Removal of Electrical Box / PCBs / Swing Motor
Step
4. Remove the swing motor
for vertical blades.
1 Remove the swing shaft
on the right side.
Remove the 2 screws
2
and detach the swing
motor assembly.
Remove the 2 screws
3
and remove the swing
motor.
14
Procedure
Swing motor assembly
Hooks
Hooks
Remove the swing shaft.
(1) Unfasten the hook.
(2) Pull out the swing shaft.
(R2789)
(R2791)
The assembly has 6 hooks.
Swing motor
(R5481)
Si04-753
Points
(R9075)
Removal Procedure
