Implants
Synex with small endplates (green)
The green Synex implants (small endplates) are used
in the upper to midthoracic spine. They are available
with -5° kyphotic endplates in a range of heights.
Angle
Height Range
495.320
-5º
20 mm – 25 mm
495.315
-5°
23 mm – 31 mm
495.318
-5°
28 mm – 40 mm
495.325
-5°
36 mm – 56 mm
Synex with small endplates (green), open
Angle
Height Range
04.807.120
-5°
20 mm – 25 mm
04.807.123
-5°
23 mm – 31 mm
04.807.128
-5°
28 mm – 40 mm
04.807.136
-5°
36 mm – 56 mm
Note:
Implants shown actual size.
18
Synthes Spine Synex System Technique Guide
Angulation
kyphotic
21 mm x 22 mm
kyphotic
kyphotic
kyphotic
Angulation
kyphotic
kyphotic
kyphotic
kyphotic
21 mm x 22 mm
-5°
495.318
