Synex Low Profile Parallel Distractor Disassembly and Assembly
Disassembly
a b
1
Open distractor
Instrument
389.202 Synex Low Profile Parallel Distractor
a
Open the distractor completely by turning the T-handle clock-
wise until the red line (a) on the shaft is visible. Turn the locking
bolt (b) counterclockwise until it disconnects from the spreading
instrument. Remove the locking bolt from the shaft.
2
Disengage T-handle
Disengage the T-handle from the hex-head (c) by pulling on
the distractor blade.
c
