Page 2
Document 2404 Instruction Manual Rev. G Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Revisions LTR. DESCRIPTION CHK. APV. A204- 100 INITIAL ISSUE Corrected Headers on sheets 6-11 A204-247 10/14/04 Revised title page copyright and deleted patent A206-369 9/28/06 pending;...
Page 3
Document 2404 Instruction Manual Rev. G Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Product Warranty Refer to Eaton’s Crouse-Hinds Airport Lighting Products Terms and Conditions for product specific warranty information.
Page 4
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Safety Notices NOTICE: This equipment is normally used or connected to circuits that may employ voltages that NOTICE are dangerous and may be fatal if accidentally contacted by operating or maintenance personnel.
Page 5
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture SAFETY SYMBOLS DANGER: DANGER The hazard or unsafe practice will result in severe injury or death. WARNING: WARNING The hazard or unsafe practice could result in severe injury or death. CAUTION: CAUTION The hazard or unsafe practice could result in minor injury.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Part Number Explanation – Runway Centerline / Touchdown Zone Light FAA TYPE: A = RUNWAY CENTERLINE LIGHT B = TOUCHDOWN ZONE LIGHT FAA STYLE: COLOR FILTERS: CC = CLEAR/CLEAR (L-850A) CR = CLEAR/RED (L-850A)
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture General Description Runway Centerline Light, L-850A The Crouse-Hinds Style 3 Runway Centerline Light is an ITS verified FAA L-850A per FAA AC 150/5345- 46C. It is designed for installation at the centerline of runways or any other location where visual guidance of moving aircraft or ground vehicles is desirable.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Installation 8.1 Installation The Style 3 RCL/TDZ light units are shipped complete, including the lamp(s), and are ready for installation as received. Installation of a light unit is to be done with primary POWER OFF and SECURED.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture WARNING: 12” RCL/TDZ optical assemblies are designed to withstand a maximum torque of 28 ft-lb WARNING (336 in-lb) per bolt, assuming K=.18 lubricant and appropriate superior-grade 3/8” hardware, however other components within the light fixture installation (i.e.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Relamping Warning - Light assembly parts are hot when lamp is energized and remain hot for a short time after lamp/fixture is turned off. Remove and secure power to the fixture.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Note – The groove is designed to be wider than the gasket. This provides room for displacement of the gasket when compressed between the housing and mating surface.
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture 9.6 Pressure Test A light fixture should be subjected to a 20-psi air pressure test to verify that it is waterproof whenever it has been opened or components have been replaced. A tire valve style pressure fitting is located on the bottom of the inner cover.
Page 14
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Optical Assembly hold-down bolts should be checked for proper torque per section 8.2. Light 9.8.4 fixtures in and around the Touchdown Zone area are especially prone to vibration damage if the mounting bolts are not properly torqued.
Page 15
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Figure 1 19999 Installation (Lifting) tool...
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture 10 Parts List PART 850A3- CC 850AC - 850A3- RX 850B3- C 850BC -C X NUMBER ITEM DESCRIPTION 21100 BRACKET, LENS RETAINING, 18-8 STN STL CLEAR LENS, REPLACEMENT KIT (LENS, 21126-C GASKET, BOOT, SILICONE, GREASE)
Page 17
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Figure 2 Top View of Fixture Figure 3 Side View of Fixture...
Page 18
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Figure 4 Bottom View of Fixture Figure 5 Inner Cover Lamp Bracket Positioning...
Page 19
Document 2404 Rev. G Instruction Manual Style 3 Runway Centerline, Touchdown Zone single piece aluminum inset fixture Figure 6 Cut Away View of Fixture...
