Linak TECHLINE LA12 Connection Diagram page 2

Connection diagram
Absolute positioning - Mechanical potentiometer feedback
12XPXX-XXXXXXX0
Please be aware that if the power supply is not properly connected, you might damage
the actuator!
F O R M O U N T I N G I N S T R U C T I O N S A N D G U I D A N C E I N U S A G E , P L E A S E S E E T H E R E L E V A N T U S E R ' S M A N U A L S
RED
BLUE
+
GREEN
YELLOW
BLACK
-
5
2019 © LINAK A/S
