Forest garden 8 x 8 Summer House Manual

8' x 8' Summer House
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
Check all parts prior to assembly
- Most buildings are pre-treated with a factory base coat for protection
during storage and transit. We recommend that you treat your new
building as soon as possible after assembly using a wood preservative
treatment. Apply in accordance with the manufacturers instructions.
- Timber is a natural material. It will shrink and swell as a result of
varying moisture content.
- Please keep all plastic bags and small parts away from children
- This product must be built on a solid level base.
Technical Help line: 0333 7777 089 8.30 am and 5.00 pm Monday to
Friday.
In line with your statutory rights, please check all parts prior to
Assembly, as assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled to. If the
product is not constructed in accordance with the instructions, or is
altered in anyway (e.g. painted), the manufacturer cannot be held liable
for any resulting damage
Fixing Pack (ASUM88FP)
Tower Bolt Qty 2
(supplied with 6 x 20mm screws)
Handle Qty 2
(supplied with 20mm screws)
Press Lock set
Qty 1
Casement Stay
Qty 1
Turn Button
Qty 2
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL

Parts:

A
ASUM88DE
DOOR PANEL QTY 1
Not to Scale
F
Window Hinge
Qty 2
Hinge
Qty 4
ASUM88VER
VERANDA QTY 1
M
Corner Brace
Qty 2
N
O
40120650PARDTR (650mm) STRIP QTY 1
P
40120500PARDTR (500mm) STRIP QTY 1
Q
40120800PARDTR (800mm) STRIP QTY 2
R
35280848PARGDTR (848mm) BATTEN QTY 4
Forest Garden Ltd. Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
SHARP KNIFE
FOR ROOFING FELT
HAMMER
TAPE MEASURE
B
ASUM88PE
PLAIN END QTY 1
G H
ASUM88VRF
SUMPDRLHDTR
ROOF QTY 4
LEFT HAND DOOR
22121710PARDTR STRIP QTY 4
40121785PARDTR (1785mm) STRIP QTY 2
Important :
Assembly of this
summer house
requires a
minimum of two
adults.
MUST PRE DRILL
C D
ASUM88PS ASUM88WS
PLAIN SIDE QTY 1 WINDOW SIDE QTY 1
I J K
OW556X672DTR
ASUM88HR
QTY 2
FRAME QTY 1
SUMPDRRHDTR
RIGHT HAND DOOR
S
80121350PARDTR (1305mm) BOARD QTY 4
T
45281800PARDTR (1800mm) BATTEN QTY 1
U
40120800PARDTR (800mm) STRIP QTY 2
V
45281747PARA1DTR (800mm) POST QTY 2
W
121121270PARDTR (1270mm) BOARD QTY 4
FIN20010512DTR
X
FINIAL QTY 2
ISSUE 0414
E
ASUM88FL
FLOOR QTY 1
L
PW860410
WINDOW QTY 2
WINDOW
85008
