- Page 1 Tiles Installation Manual ™ Complete instructions to install the Friant Tiles panel system ™...
-
Page 2: Table Of Contents
Introduction ................................3 Tile Assembly, Frames, Connectors, and Change of Height Wedge Installation ......................4 Tiles Assembly, Frames, Connectors, and Change of Height Wedge Installation ..........5 Connectors Cover, Finished End Cover, Finished End Change of Height Cover, Installation ........................6 Stacking Frame, and Stacking Connector Installation .................. -
Page 3: Introduction
Reconfiguration of the product and additions to an installation must be performed per the instructions in this manual to ensure the continued safe use of the product. Friant & Associates, LLC does not assume any responsibility for product that is altered in any way. -
Page 4: Tile Assembly, Frames, Connectors, And Change Of Height Wedge Installation
Position Frame so that notched Tab on the Frame is fitted between shoulders of adjacent Cap Screw of Draw Rod. Hold Frame against Connector and tighten Cap Screw until Frame and Connector come together. Page 4 Tiles Installation Manual ™... -
Page 5: Tiles Assembly, Frames, Connectors, And Change Of Height Wedge Installation
Tiles Assembly, Frames, Connectors, and Change of Height Wedge Installation Frame to Unequal Height Frame Remove Change of Height Wedge from the hardware package supplied with Change of Height Finished End. Insert Change of Height Wedge in Taller Frame Channel opening that matches Frame the height of the shorter Frame’s... -
Page 6: Connectors Cover, Finished End Cover, Finished End Change Of Height Cover, Installation
Frame or Con- nector, remove the Cover and adjust the Extended Tabs until the Cover sits flush. Do not use a rubber mallet to force the Cover down. Page 6 Tiles Installation Manual ™... -
Page 7: Stacking Frame And Stacking Connector Installation
Position Stacking Connector on top of exist- ing Connector, engage Draw Nut into the rectangular slots in both the Frame and the Connector, and tighten screw. Install Top Cap onto Stacking Connector. Install Replacement Cover. Page 7 Tiles Installation Manual ™... -
Page 8: 8-Wire Electrical, Base Feed Installation
Ensure Base Feed that the Connector is fully engaged. Press further until the spring tab clicks into position.Return the Base Cover to the closed position. Return the Base Cover to the closed position. Page 8 Tiles Installation Manual ™... -
Page 9: 8-Wire Electrical, Base Power Retro, And Beltline Power Retro Installation
Bar and line up holes in the Power Retro mounting bracket with the holes in the Frame Support Bar. Secure with the Self Tapping Screws provided and tighten securely. Power Retro Connect Festoon to the Power Retro. Support Bar Page 9 Tiles Installation Manual ™... -
Page 10: 8-Wire Electrical, Beltline Power Retro Duplex Clip Installation
Insert Clip at an angle into slits on top of Duplex Outlet the Beltline Power Support Bar. Straighten Clip and slide Clip, either left or right, over the Duplex Outlet. Beltline Power Support Bar Clip Duplex Outlet Beltline Power Support Bar Page 10 Tiles Installation Manual ™... -
Page 11: 8-Wire Electrical, In-Frame Power Jumper And Pass-Through Power Jumper Installation
Frames to be connected. Lay Flex Conduit at the bottom of the wire management. Connect Pass-Through Power Jumper to Power Retro on adjacent Frames. Press until fully engaged, and the spring tab clicks into position. Page 11 Tiles Installation Manual ™... -
Page 12: 8-Wire Electrical, Beltline Power Transfer Installation
Connector Post. Secure bottom of Flex Conduit to Frame with plastic Tie Strip provided. Make sure that both connections are fully engaged, and the spring tabs click into position. Page 12 Tiles Installation Manual ™... -
Page 13: Fabric Tiles, Marker Board Tiles, Perforated Tiles, And Window Tiles Installation
Fabric Tiles, Marker Board Tiles, Perforated Tiles, and Window Tiles Installation Note: Install Tiles from bottom to top on a Frame. Beltline power and electrical components should be installed pirior to Top Clip other tiles. Tile Fabric Tiles, Marker Board Tiles,... -
Page 14: Rail Tiles, Power And Data Tiles Installation
Rail Tiles, Power and Data Tiles Installation Tiles can be removed individually from any position. When more than one Tile is removed from the same Frame, remove the Frame upper Tile first. Screws Rail Tiles Installation is the same for other Tiles... -
Page 15: Shelf Ends And Shelf Installation
Line up the slots on each sides of the Shelf with Mounting Screws on each Shelf End. Press down on Shelf. Ensure Shelf is fully seated on the Mounting Screws. Tighten all Mounting Screws. Shelf Shelf Ends Shelf Mounting Screw Page 15 Tiles Installation Manual ™... -
Page 16: Flipper Door Unit Door/Cover Installation
Push Door/Cover Assembly back until front slots in door guides drop over Front Mounting Screws. Make sure the Door/Cover Assembly is fully seated onto Mounting Screws. Door/Cover Assembly Tighten all Mounting Screws Front Mounting Screws Page 16 Tiles Installation Manual ™... -
Page 17: Worksurface Installation
Worksurface. See picture on next page. Level Worksurface by adjusting the leveling screw at the front of the Cantilever Brackets. Install adjacent Worksurfaces as required. 10. Attach Ganging Plates between adjacent Worksurfaces. Page 17 Page 17 Tiles Installation Manual ™... -
Page 18: Worksurface Installation
See picture at left. 10. Level Worksurface by adjusting the leveling screw at the front of the Cantilever Brackets. 11. Install adjacent Worksurfaces as required. 12. Attach ganging plates between adjacent Worksurfaces. Page 18 Page 18 Tiles Installation Manual ™... -
Page 19: Worksurface Installation
Cantilever Brackets. Install Front Spacers. Install adjacent Worksurfaces if needed. Level Worksurface by adjusting the lev- eling screw at the front of the Cantilever Brackets. Attach ganging plates between adjacent Worksurfaces. Page 19 Page 19 Tiles Installation Manual ™... -
Page 20: Transaction Surfaces Installation
Transaction Surfaces Installation Rectangular Transaction Surface Remove Top Tiles from both sides of Screws Frame. Remove existing Frame Top Cap from Mounting Brackets Frame and store for future use. Secure Mounting U-shape Brackets (pro- vided) to the bottom of the Transaction Surface, using the pre-drilled holes. -
Page 21: Worksurface Support End Panels, And Half Leg Installation
End Panel or Half Leg. Push Worksurface back until Front Spacer screw drops into front hole of Support Panel. For Half Legs, install Ganging Plates between adjacent Worksurfaces. Page 21 Page 21 Tiles Installation Manual ™... -
Page 22: Open Metal Worksurface Support Installation
Note: Safety Clip must be secured to Open Return and Frame. Failure to do so could cause product instability and/or physical injuries. Install Corner Worksurface Bracket to Corner Worksurface Bracket match the height of the Bracket Assembly. Install Worksurface. Page 22 Page 22 Tiles Installation Manual ™... -
Page 23: Door Frame Installation
Frame must be parallel to the flat face of the door. Loosen bottom screws on each side of opening above Threshold. Press Thresh- old to floor and tighten screws. Position Trim Strips and press in place. Threshold Screw Page 23 Page 23 Tiles Installation Manual ™... -
Page 24: Supporting Pedestals And Lateral Files Installation
Work- surface. If it is not the correct height, adjust the Glides on the Lateral File or raise the Worksurface. To install the Lateral File, repeat the above steps. Page 24 Page 24 Tiles Installation Manual ™... - Page 25 4901 EAST 12th St / Oakland / California 94601 / T: 510.535.5113 / F: 510.535.5237 / friant.com 5.1.10...
