EEI –2772/2653
Thank you for purchasing the MODWAY OFFICE CHAIR！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the office chair, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approxi mate assembly time: 15 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
Component:
A Chair Back
X1
E Control Mechanism
X1
Customer Service 908-368-1025︱www.modwayfurniture.com
OFFICE CHAIR
A
B
D
F
G
H
H
H
B Right Armrest
X1
X1
F Cylinder
Hardware:
1
2
3
4
C
E
H
H
C Left Armrest
X1
G Chair Base
X1
Bolt M8*25mm
Bolt M8*30mm
Flat Washer 8*17mm
Allen Wrench
D Chair Seat
X1
X5
H Castors
X3
X8
X7
X1
Page 1 of 4
Advertisement
Table of Contents
Related Manuals for modway EEI-2772
Summary of Contents for modway EEI-2772
- Page 1 EEI –2772/2653 OFFICE CHAIR Thank you for purchasing the MODWAY OFFICE CHAIR！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 EEI –2772/2653 OFFICE CHAIR STEP 1: Please put Chair Base (G) upside down on a carpeted or padded surface. Insert 1pc of Castor (H) into the Chair Base (G) as shown by hand. Repeat the same steps for the remaining 4pcs of Castor (H). STEP 2: Flip the assembled Chair Base (G) with Castors (H) on the floor.
- Page 3 EEI –2772/2653 OFFICE CHAIR STEP 3: Please put the Chair Seat (D) upside down on a carton. Attach Chair Right Armrest (B) and Left Armrest (C) into the bottom of Chair Seat (D) by using 4 pieces of Bolt (2) as shown.
- Page 4 EEI –2772/2653 OFFICE CHAIR STEP 5: Please put the assembled Chair Seat (D) upside down on a carton. Attach Control Mechanism (E) into the bottom of Chair Seat (D) by using 2 pieces of Bolt (1) and 2 pieces of Bolt (2) with 4 pieces of Flat Washer (2) as shown.
