EEI –2772/2653
STEP 5:
Please put the assembled Chair Seat (D) upside down on a carton.
Attach Control Mechanism (E) into the bottom of Chair Seat (D) by using 2 pieces of Bolt (1) and 2 pieces of Bolt (2)
with 4 pieces of Flat Washer (2) as shown.
Use Allen Wrench (4) to tighten all Bolts (1) and Bolts(2) clockwise until secure.
1. 2.
2x2pcs
1x2pcs
STEP 6:
Carefully turn over the assembled Chair Back (A), Right Armrest (B), Left Armrest (C),Chair Seat (D) and Control
Mechanism (E). Please insert the bottom holes of Control Mechanism (E) into the top end of assembled Cylinder (F)
as shown. Sit on Chair Seat (D) to fully tighten the office chair.
Assembly is complete. The office chair is ready to be enjoyed now!
Customer Service 908-368-1025︱www.modwayfurniture.com
OFFICE CHAIR
A
3. 4.
4x1pcs
3x4pcs
1
3
E
1
3
B
D
C
2
4
3
2
3
Hardware & Tool required
Page 4 of 4
