1A
Parts in Box 1 of 2:
Headboard x 1
1B
Parts in Box 2 of 2:
Stretcher x 2
1C
Hardware in Box 2 of 2:
Bolts (12mm) x 8
For the Headboard
and Footboard
Assembly Instructions for Antero Bed, Full & Queen
Footboard x 1
Bolts (70mm) x 1
For the Center Slat
Support Foot
Strata
urniture
Watch our assembly videos at www.stratafurniture.com/videos.html
Bolts (90mm) x 2
For the Outside Slat
Support Feet
Page 1 of 4
Slats x 1
Center Rail x 1
Screw x 24
For Slats
One for 12mm Bolts,
One for 70mm & 90mm Bolts
Slat Support Feet x 3
Allen Key x 2
Advertisement
Table of Contents
Related Manuals for Strata Furniture Antero Bed Full
Summary of Contents for Strata Furniture Antero Bed Full
- Page 1 Strata urniture Assembly Instructions for Antero Bed, Full & Queen Watch our assembly videos at www.stratafurniture.com/videos.html Parts in Box 1 of 2: Headboard x 1 Slats x 1 Slat Support Feet x 3 Footboard x 1 Parts in Box 2 of 2: Center Rail x 1 Stretcher x 2 Hardware in Box 2 of 2:...
- Page 2 Strata urniture Assembly Instructions for Platform Bed, Full & Queen Insert 12mm Bolts into Headboard and Footboard. Connect the Stretchers to the Headboard and Footboard. Leave bolts loose! Drop Stretcher bracket over 12mm Bolts on Headboard and Footboard as shown. Tighten all 12mm Bolts with Allen Key.
- Page 3 Strata urniture Assembly Instructions for Platform Bed, Full & Queen Roll slats out on top of Stretchers with Strip-side down. Attach one of the Slat Support Feet to the Center Make sure slats are evenly spaced! Rail using the 70mm Bolt as shown. Place Center Rail beneath the slats so it aligns with pre-drilled holes in the slats.
- Page 4 Strata urniture Assembly Instructions for Platform Bed, Full & Queen Using 90mm Bolts, attach remaining Slat Support Feet to Slats and Attach Slats to Stretchers using Screws as shown. Center Rail as shown. An electric screwdriver is helpful for this step. 90mm Bolt Stretcher Headboard*...
