Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
Additionally, the following parts may belong to the documentation, if applicable: • EU-type examination certificate • EU declaration of conformity • Attestation of conformity • Certificates • Control drawings • FMEDA report • Assessment report • Additional documents For more information about Pepperl+Fuchs products with functional safety, see www.pepperl-fuchs.com/sil.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Introduction Safety Information Target Group, Personnel Responsibility for planning, assembly, commissioning, operation, maintenance, and dismounting lies with the plant operator. Only appropriately trained and qualified personnel may carry out mounting, installation, commissioning, operation, maintenance, and dismounting of the product. The personnel must have read and understood the instruction manual and the further documentation.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid property damage.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Product Description Product Description Function KCD2-SR-1.LB(.SP) This signal conditioner provides the galvanic isolation between field circuits and control circuits. The device transfers digital signals (NAMUR sensors or dry contacts) from the field to the control system. The proximity sensor or the mechanical contact controls the normally open relay output for the control side load.
Page 8
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Product Description KCD2-SR-2(.SP) This signal conditioner provides the galvanic isolation between field circuits and control circuits. The device transfers digital signals (NAMUR sensors or dry contacts) from the field to the control system. The proximity sensor or the mechanical contact controls the normally open relay output for the control side load.
Page 9
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Product Description HiC2821 This isolated barrier is used for intrinsic safety applications. The device transfers digital signals from NAMUR sensors or dry contacts from the hazardous area to the non-hazardous area. The proximity sensor or the mechanical contact controls the normally open relay output for the control side load.
KCD2-SR-(Ex)2(.SP), HiC2822: input I, input II, output I, output II • Non-safety relevant interfaces: fault output Note! For corresponding connections see datasheet. Marking Pepperl+Fuchs GmbH Lilienthalstraße 200, 68307 Mannheim, Germany Internet: www.pepperl-fuchs.com KCD2-SR-1.LB(.SP), KCD2-SR-Ex1.LB(.SP) Up to SIL 2 KCD2-SR-2(.SP), KCD2-SR-Ex2(.SP)
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Planning Planning System Structure 3.1.1 Low Demand Mode of Operation If there are two control loops, one for the standard operation and another one for the functional safety, then usually the demand rate for the safety loop is assumed to be less than once per year.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Planning Assumptions The following assumptions have been made during the FMEDA: • Failure rate based on the Siemens standard SN 29500. • Failure rates are constant, wear is not considered. • External power supply failure rates are not included. •...
Page 13
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Planning DIP Switch Settings 1-channel Devices Function Mode KCD2-SR-(Ex)1.LB(.SP) HiC2821 Mode of operation normal mode S1 position I S1 position II output I inverted mode S1 position II S1 position I Assignment output II follow output I S2 position I S3 position I LB/SC detection...
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Planning Characteristic Safety Values Parameters Characteristic values Assessment type and Full assessment documentation Device type Mode of operation Low Demand Mode or High Demand Mode SIL (SC) Safety function 1 relay output for 1 channel 2 relay outputs for a 1-channel device 99 FIT 126 FIT...
As noted in DIN EN 61508-2:2011 note N3, appropriate measures taken by the manufacturer and plant operator can extend the useful lifetime. Our experience has shown that the useful lifetime of a Pepperl+Fuchs product can be higher if the ambient conditions support a long life time, for example if the ambient temperature is significantly below 60 °C.
Page 16
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Planning Maximum Switching Power of Output Contacts The useful life time is limited by the maximum number of switching cycles under load conditions. The maximum number of switching cycles is depending on the electrical load and may be higher when reduced currents and voltages are applied. You can see the relationship between the maximum switching power and the load conditions in the figures below.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Mounting and Installation Mounting and Installation Mounting and Installing the Device 1. Observe the safety instructions in the instruction manual. 2. Observe the information in the manual. 3. Observe the requirements for the safety loop. 4. Connect the device only to devices that are suitable for this safety application. 5.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Operation Operation Danger! Danger to life from missing safety function If the safety loop is put out of service, the safety function is no longer guaranteed. • Do not deactivate the device. • Do not bypass the safety function. •...
Page 19
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Operation Proof Test Procedure 1. Put out of service the entire safety loop. Protect the application by means of other measures. 2. Prepare a test set-up, see figures below. 3. Simulate the sensor state by connecting a potentiometer, a resistor for short circuit detection or by a resistor for lead breakage detection.
Page 20
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Operation Multimeter KCD2-SR-Ex2 (mA) 240 Ω/2.5 W 24 V DC Multimeter (mA) Multimeter (mA) 240 Ω/2.5 W 24 V DC Multimeter (mA) Multimeter (mA) 24 V DC Power Zone 0, 1, 2 Zone 2 supply Div. 1, 2 Div.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* Maintenance and Repair Maintenance and Repair Danger! Danger to life from missing safety function Changes to the device or a defect of the device can lead to device malfunction. The function of the device and the safety function is no longer guaranteed. Do not repair, modify, or manipulate the device.
Functional Safety KCD2-SR-(Ex)*(.LB)(.SP), HiC282* List of Abbreviations List of Abbreviations Emergency Shutdown Failure In Time in 10 FMEDA Failure Mode, Effects, and Diagnostics Analysis Probability of safe failure Probability of dangerous detected failure Probability of dangerous undetected failure ...
Page 24
