Summarization of Contents
Introduction
Content of this Document
Details the scope of the document for device usage in functional safety applications.
Safety Information
Information for target groups, personnel, and intended use of the device.
Symbols Used
Explanation of warning and informative symbols used in the document for clear communication.
Product Description
Function
Describes the general purpose and specific functions of the switch amplifier models.
Interfaces
Details the safety-relevant and non-safety-relevant interfaces of the device.
Marking
Provides company identification and website for the product.
Standards and Directives for Functional Safety
Lists device and system-specific standards and directives related to functional safety.
Planning
System Structure
Discusses system structure for Low Demand and High Demand/Continuous modes of operation.
Assumptions
Lists assumptions made during the FMEDA for SIL 2 applications and failure rate calculations.
Safety Function and Safe State
Defines the safe state and modes of operation for the safety function.
DIP Switch Settings 1-channel Devices
Details DIP switch configurations for 1-channel devices for safety-relevant applications.
DIP Switch Settings 2-channel Devices
Details DIP switch configurations for 2-channel devices for safety-relevant applications.
LB/SC Diagnosis
Explains line fault (LB) and short circuit (SC) diagnosis for input loops.
Characteristic Safety Values
Presents key safety parameters like PFH, PFDavg, SFF, HFT, and reaction time.
Useful Lifetime
Discusses the concept of useful lifetime for components based on failure rate assumptions.
Mounting and Installation
Configuration
Details the process of configuring the device using DIP switches.
Operation
Operating the device
General instructions for operating the device safely and correctly.
Proof Test
Explains the requirement and procedure for recurring proof tests on the device.
Proof Test Procedure
Step-by-step guide for performing the proof test on the device.
Maintenance and Repair
Maintaining, Repairing or Replacing the Device
Procedures and safety precautions for maintaining, repairing, or replacing the device.
