EN
User's manual

IMPORTANT INFORMATION

To ensure the optimal functioning of your camera, please note the following important
information:

MicroSD card:

• Please ensure your memory card is formatted in the camera before first using the card for
the first time (Settings > Format).
• The maximum capacity memory card supported is 64GB.
Use of memory cards exceeding the maximum recommended capacity may result in file
errors.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GoXtreme Enduro Black and is the answer not in the manual?

Questions and answers

Related Manuals for Easypix GoXtreme Enduro Black

Summary of Contents for Easypix GoXtreme Enduro Black

  • Page 1 User’s manual IMPORTANT INFORMATION To ensure the optimal functioning of your camera, please note the following important information: MicroSD card: • Please ensure your memory card is formatted in the camera before first using the card for the first time (Settings > Format). •...
  • Page 2 • For best results, we recommend using high quality Micro SD cards Class 10 with U3 High Speed or higher. Ensure a U3 rated memory card is used when recording 4K video. Using a lower rated card may present data transfer speed issues due to the large file size a 4K video produces. •...
  • Page 3 WiFi connection: • Ensure you have downloaded the correct companion app for your camera model. • Please note that wireless transfer of files using the app is not possible for video with resolution higher than 1080p. Files using any resolution higher than 1080p can only be accessed via your computer using a card reader.
  • Page 4 With a wide selection of accessories and mounts including the 30M waterproof case available out of the box, the GoXtreme Enduro Black is ready for your next adventure. Product features Includes waterproof case, allowing you to record HD video at up to 30M depth.
  • Page 5 HDMI Output Web Camera function Supports SD card memory expandable up to 64GB (Maximum) Supports multiple video recording formats: 4K (interpolated)/2.7K/1080P/720P Camera...
  • Page 6 1. Installing a Micro SD Card Note: Please choose a branded Micro SD card, and then format it with the computer before use. We suggest a high quality SD card for the perfect result. Maximum card capacity is 64GB (Class 10 or above) 2.
  • Page 7 4. Switching the camera on and off Press and hold the power switch for 2 seconds to turn it on/off You can also switch it on/ off trough the LCD screen display menu. 5. Mode Switching Switch between video recording / photo shooting / slow motion video / playback / settings by pressing the power button as mode function.
  • Page 8 6.2. Photo shooting Switch the camera on and press “Mode” to select “Photo shooting Mode”, you will see the icon in the upper left corner of the screen display and the camera is in photo shooting mode. Press “OK” to take photos. 6.3.
  • Page 9 6.5. Setting Press the "Power / Mode" button and go to the settings: When the symbol is displayed on the camera screen, press the "OK" button to enter the settings. Press the "Power / Mode" button to switch between the setting categories. Use the "UP"...
  • Page 10 Ensure the WiFi function is active on your smart device, go to settings and search for the camera’s WiFi account. Connect the smart device and camera using password “12345678” which will display on screen. This action is only required on initial set up or following a system reset.
  • Page 11 Slow Motion (1080P@60FPS/720P@120FPS) Selects the resolution at which slow motion video will be recorded. Date Stamp (Off, On) Select 'On' to add a date and time display to your recordings. Image Size 16M/12M/8M/5M/2M Selects the still image resolution. Burst Photo (Off, 3 Sequence, 5 Sequence, 10 Sequence) When activated the camera takes a rapid burst of 3, 5 or 10 images.
  • Page 12 White Balance (Auto, Sunny, Cloudy, Incandescent Light, Fluorescent Light) Selects your preferred White Balance setting from a number of pre-set options. Date/Time (and how to set) When connected to a smartphone the time and date synchronize automatically. However the Date/Time menu option allows you to manually set the time and date if required. Press the up / down buttons on the side of the camera to increase or decrease the selected field .
  • Page 13 Frequency (50 Hz, 60 Hz) Select to match the frequency of the electricity network in your country. An incorrect setting may cause a flickering effect in videos in artificial light. Screensaver (Off, 10S, 20S, 30S) To help prolong battery life the camera screen can be set to turn off after a preset period of time.
  • Page 14 Version Displays the camera system settings. Webcam function (for Windows only) Connect the camera to your PC using a USB cable, then select the "PC Camera" function shown in the display. PLEASE NOTE: Please note that the web cam function provides video only and does not include audio. A headset or earphones with in-line mic as provided with many smartphones is required for audio.
  • Page 15 10. Technical data Display (LCD) 2.0” LTPS Lens 170°A+ HD wide-angle lens Video resolution 4K@30fps (by interpolation) 2.7K@30fps 1080p @60fps/30fps 720p@120fps/60fps/30fps Video format Compressed video H.264 format Sensor 8MP SONY179 Sensor Photo resolution 16M by interpolation, 12M by interpolation, 8M, 5M, 2M Storage Micro SD up to 64GB Class 10 or above Shooting mode...
  • Page 16 Battery 900mAh Power dissipation 400mA@4.2V Recording time 1080p/ About 90 minutes Charging time About 3hours Operating system WindowsXP/Vista/Win7/Win8/Win10/Win8/Win10/Mac OS (OS) Dimensions 59 x 41 x 32 mm NOTE: The original specification may vary from time to time due to product upgrading and updating.
  • Page 17 All product specifications are correct at time of print and are subject to change without prior notice. Easypix GmbH reserve the right for errors or omissions. For technical help please visit our support area on www.easypix.eu.
  • Page 18 The manufacturer hereby declares that the CE marking was applied to the product GoXtreme Enduro Black in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2014/53/EU 2011/65/EC RoHs 2014/30/EU EMV 2012/19/EC WEEE The EC Declaration of Conformity can be downloaded here: http://www.easypix.info/download/pdf/doc_goxtreme_enduro_black.pdf...
  • Page 19 DISPOSAL Dispose of packaging For disposal, separate packaging into different types. Cardboard and board must be disposed of as paper and foil must be recycled. Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in private households in the European Union. This symbol on the product or on the packaging indicates that this cannot be disposed of as a household waste.
  • Page 20 Battery warning • Never dismantle, crush, or pierce the battery, or allow the battery to short-circuit. Do not expose battery being placed in high temperature environment, if battery leaks or bulges, stop continue to use. • Always charge using the charger. Risk of explosion if battery is replaced by an incorrect type.
