MANUAL
Foreword
Thank you for purchasing this digital camera. Please carefully read through this
product manual before using, and keep this manual properly for future reference.
Contents of the product manual are based on the updated information when
compiled. The screen display and figures used in the manual are for detailed and
visual operation of the camera. Due to technical development and different
production lots, they may differ from the digital camera you actually use.
Operation Notice
This camera uses the TF card (Multimedia memory card)
Instructions for using the memory card
For the first time of using a new memory card, or when there is unrecognized
data for the camera or images shot with other cameras in the memory card,
please make sure to firstly format the memory card;
Please power the camera off before plugging in or taking out the memory card;
After using for many times, performance of the memory card will get lower. In
case of lower performance of the memory card, please buy a new one;
The memory card is a precision electronic device. Please do not bend the card
and prevent from falling down or heavy load on it;
Keep the memory card away from the environment with strong
electromagnetic field or magnetic field like places close to speaker or TV
receiver;
Keep the memory card away from the environment with over high or low
temperature;
Keep the memory card clean and prevent it from contacting liquid. In case of
liquid contacted, clean and dry it with a piece of soft cloth;
In case of idle use, please keep the memory card in a guard staple;
Please note that the memory card will get hot after long-term use, and this is
normal;
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1.3 Mega pixel and is the answer not in the manual?

Questions and answers

Summary of Contents for Easypix 1.3 Mega pixel

  • Page 1 MANUAL Foreword Thank you for purchasing this digital camera. Please carefully read through this product manual before using, and keep this manual properly for future reference. Contents of the product manual are based on the updated information when compiled. The screen display and figures used in the manual are for detailed and visual operation of the camera.
  • Page 2 Do use the memory card having been used on other digital video recorder or digital cameras. In case of using the memory card, please firstly format it; Using the memory card formatted with other digital video recorders or digital cameras are prohibited; In case of one of the followings for the memory card, the recoded data may be damaged: - Improper use of the memory card;...
  • Page 3: System Requirements

    One standard USB 1.1 or USB 2.0 interface(s) Function Characteristics This camera is equipped with various characteristics and functions: l Digital video recorder; l Digital camera (1.3 Mega pixel); Black and white digital display; l Mass Storage (portable disc) l Appearance...
  • Page 4: Start Operation

    Black and white digital screen MODE key Shutter Power Microphone Lens Reset USB port TV port TF card slot Key Functions and Indictors Function Key/Indicator Power Power On/Off Video recording mode, Recording/Stop Capture mode, taking pictures Shutter Replay mode; after connecting to TV, short press to play the recorded video;...
  • Page 5: Video Recording

    Power-on Press and hold power key for 2 seconds and release it for power-on of the camera. Mode switchover After power-on, the camera enters the default mode of video recording at a default size of Lo. In video recording mode at Lo size, click MODE key to switch the size to HI;...
  • Page 6 In replay mode, long press Shutter key to enter shortcut deletion prompt, press Shutter key to confirm deletion, and press MODE key to exit from deletion. Power-off In power-on mode, long press Power key to power the camera off. Connection to computer Firstly power the camera on, and then connect the camera with attached USB cable to USB port of the computer.
  • Page 7: Advanced Operation

    Advanced Operation Video recording, capture mode After power-on, the camera automatically enters video recording mode. In video recording mode at Lo size, click MODE key to switch the size to HI; in video recording mode at HI size, click MODE key to enter capture mode at Lo size, and in capture mode at Lo size, click MODE key to return to video recording mode at Lo size.
  • Page 8 Indicates low resolution in current video Recording Lo recording mode Time left for Indicates time left in FT card for video recording recording Capture mode Indicates currently in capture mode Indicates high resolution current Capture HI capture mode Photo to be Indicates quantity photos...
  • Page 9 Icon Description Replay mode Indicates reply mode Indicates there are total 31 files, and File quantity the 19 file is being browsed currently. TF card Indicates a memory card available Icon video Indicates the current file is a video recording recording file.
  • Page 10: Specification

    File Deletion After connecting to TV, the camera enters the replay mode. In replay mode, long press Shutter key to enter file deletion mode, press Shutter key to confirm deletion, and press MODE key to exit from deletion. Connect to computer to download photo/video After connecting to computer, the camera enters portable disc mode.
  • Page 11 USB port USB2.0 TV Output Display Black and white digital screen Power supply Built-in 3.7V rechargeable lithium battery Menu language English Focal length f=5.8mm Iris aperture F2.8 Automatic power-off 3 minutes Requirements Microsoft Windows 7, 2000, XP, VISTA operating system Dimensions 48.5 x 23.5 x 33 mm Attention: Design specification of the product is based on updated...
  • Page 12 Battery low. Recharge the battery. Automatic power-off of To save power, the camera will automatically the camera power off if no any operation performed for over 3 minutes. For technical help please visit our support area on www.easypix.eu.
