DDZ5000HD-DN/IR Series
COMMISSIONING
007678 | REV. 1.0.1 | 2019-11-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDZ5000HD-DN/IR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dallmeier DDZ5000HD-DN/IR Series

Summary of Contents for dallmeier DDZ5000HD-DN/IR Series

  • Page 1 DDZ5000HD-DN/IR Series COMMISSIONING 007678 | REV. 1.0.1 | 2019-11-20...
  • Page 2 Mozilla and Firefox of Mozilla Foundation headquartered in Mountain View, California, USA. Third-party trademarks are named for information purposes only. Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights.
  • Page 3 COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 5: Table Of Contents

    10 Parts Description and Connections 11 Pin Assignment 12 Configuration System Requirements Establishing the Connection First-Time Access Login 13 Limits of the System 14 Technical Product Specification (Basic Data) 15 Dimensions COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 6: Validity

    Keep all documents in legible condition and in a suitable location for future reference. Regularly check the website www.dallmeier.com for the latest product documentation updates. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 7: This Document

    The document entitled “Configuration” contains detailed information con- cerning the configuration of the device. The target audience of the document is trained system integrators (installa- tion contractors of video security/surveillance systems). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 8: Typographical Conventions

    NOTICE addresses practices not related to physical injury and indicates measures to prevent device and/or property damage due to improper installation, assembly, wiring, operation, configuration or maintenance of the device. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 9 (menu items, buttons, etc.). Paragraphs in italics provide information on basic principles, special features and efficient procedure as well as general recommendations. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 10: Approvals/Certifications

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interfer- ence at his own expense. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 11: Safety Instructions

    Do not make any modifications to the hardware or software of the device that have not been tested and approved by Dallmeier. Inappropriate modifications may cause malfunctions, damage and data loss and may result in the loss of warranty. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 12 DIN, VDE and ISO standards and which provide for a standard-compliant earthing/grounding and a correct equipotential bonding of electrical and electronic devices, are mandatory and must be fulfilled by all means. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 13 Do not dispose waste electrical and electronic equipment into the house- hold trash. Disconnect the device from the power supply. Remove all connected peripherals. Return the device to the sales partner responsible for your area. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 14: General Notes

    The device should only be shipped in the original packaging. If the original packaging is no longer available, ensure that the used packag- ing sufficiently protects the device against damage, moisture, heat and cold. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 15: Warranty

    (24/7/365 continuous operation). The cameras of the DDZ5000HD-DN/IR series are designed exclusively for hanging installations on ceilings or walls (optionally available Mountera® bracket required). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 16: Operation

    Mixed light (consisting of artificial light and daylight) may cause color distortions (inaccurate color reproduc- tion). • Poor lighting can lead to an incorrect white balance. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 17: Requirements

    Use of the device under unfavorable ambient conditions may shorten its lifetime and may cause malfunction or damage to the device. ➡ Only install/operate the device under favorable ambient conditions. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 18: Earthing/Grounding

    ISO standards in order to ensure the safety of the device (protection against lightning strikes and over-voltages) and its immunity to electromagnetic interferences (EMI). Observe the locally applicable regulations regarding the minimum required cross-section of the earthing/grounding cable. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 19: Power Supply

    (see chapter “Pin Assignment” on page 54). ➡ Do not operate the device with Power over Ethernet (PoE) if the device is powered by an external DC power supply unit. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 20: Built-In Infrared (Ir) Illumination

    May be harmful to the eye ➡ Do not stare at operating IR LEDs. ➡ Use appropriate shielding or eye protection. ➡ Ensure a minimum safety distance of 1 meter and short exposure times. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 21: Maintenance, Inspection And Cleaning

    (e.g. a glasses cleaning cloth) to avoid scratching the surface. The lens protection front window of the DDZ5(4)36HD-DN/IR is made of glass, so you can use a common glass cleaner for cleaning if required. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 22: Mounting, Connection And Commissioning

    (safety cable) on the outside of the housing. In addition, strictly observe the locally applicable regulations regard- ing the mandatory measures for securing your camera system against falling while in operation. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 23 Mountera® Ceiling Bracket is described. Fig. 2: Mountera® Ceiling Bracket with internal cable routing and pre-assembled internal safety cable (secondary safety component) COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 24 ➡ Place the device in its original packaging on a level, clean and stable surface. ➡ Open the device packaging. Be careful not to damage the original packaging for future transpor- tation. ➡ Remove the accessory box. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 25 ❷ Fig. 4 ➡ Carefully pull the top foam insert out of the packaging. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 26 ➡ Carefully pull the device by its plastic handle (red) out of the pack- aging. The bottom foam insert has to be lifted out together with the device and must not be removed from the device at this time. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 27 The bottom foam insert is necessary to prevent the pan-tilt head on the bottom side of the housing from being damaged when placing down the device. ➡ Rotate the carrying handle vertically by 90°. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 28 (Fig. 7). ➡ Separate the two halves of the remaining cap and then remove both parts from the device (Fig. 8). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 29 Fig. 9 Place the individual parts of the plastic handle back into the original packaging of the device for later reuse. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 30 ❻ Fig. 10 ➡ Attach the supplied flexible rubber sleeve (bellows) from the accessory box to the connecting plate of the Mountera® Quick-Lock System. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 31 Fig. 11 ➡ Make sure that the rubber sleeve is correctly seated on all sides to prevent any moisture, dust and dirt from penetrating the device later on. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 32 ➡ Make sure that the locking screw of the Mountera® Quick-Lock System is fully open (turned in counterclockwise direction). For this purpose, use the supplied hexagon socket screw key (size 5) from the accessory box. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 33 (secondary safety component), as shown in Fig. 13, in order to pre- vent the device from accidentally falling down during the following mounting steps. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 34 ➡ Before assembling the device to the bracket, hold the device so that the adjusting screw of the Mountera® Plug is aligned with the lock- ing screw of the bracket. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 35 ➡ Insert the Mountera® Plug into the Mountera® Lock until the spring mechanism inside the bracket locks into place (make sure to keep the device straight when inserting so that the Mountera® Plug does not get jammed). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 36 ➡ Secure the Mountera® Quick-Lock System by turning the locking screw of the bracket fully in clockwise direction. For this purpose, use the supplied hexagon socket screw key (size 5) from the accessory box. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 37 ➡ Carefully remove the bottom foam insert from the device. ➡ Place the foam insert back into the original packaging of the device for later reuse. ➡ Remove the protective films from the IR LEDs. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 38 ⓬ Fig. 18 ➡ Open the rubber protective cover (captive) of the housing cover locking screw. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 39 Fig. 19 ➡ Loosen the housing cover locking screw in counterclockwise direc- tion with the supplied hexagon socket screw key (size 5). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 40 ⓭ Fig. 20 ➡ Turn the housing cover lock ring in counterclockwise direction as far as it will go. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 41 Fig. 21 ➡ Open the housing cover. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 42 Fig. 22. ➡ Carry out the cabling and a proper earthing/grounding of the device (see chapter “Parts Description and Connections” on page 52). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 43 (secondary safety component), as shown in Fig. 23, in order to prevent the device from accidentally falling down during operation. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 44 ⓰ Fig. 24 ➡ Close the housing cover. ➡ Turn the housing cover lock ring in clockwise direction as far as it will COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 45 ➡ Tighten the housing cover locking screw in clockwise direction with the supplied hexagon socket screw key (size 5). ➡ Close the rubber protective cover of the housing cover locking screw. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 46 ⓲ Fig. 26 By default, the Mountera® Plug is perpendicular to the housing. Therefore, the device should usually be exactly level to the ground after mounting. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 47 ➡ Check whether the device is exactly level to the ground by means of a spirit level. If this is not the case, follow the instructions described for Fig. 28 and Fig. 29 (see below). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 48 ➡ Turn the locking screw of the ball head with the supplied hexagon socket screw key (size 5) in counterclockwise direction (beyond a noticeable end-stop) until you can tilt the device with your hands in all directions with little effort. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 49 ➡ Using a spirit level, align the device so that it is exactly level to the ground (finally tighten the locking screw of the ball head in clock- wise direction again). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 50 ➡ If necessary, pan the device carefully and with normal force in the required direction (first turn the locking screw of the Mountera® Quick-Lock System by 180° in counterclockwise direction and tighten it again when finished). COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 51 Make sure that the rubber sleeve is correctly seated on all sides to prevent any moisture, dust and dirt from getting between the device and the Mountera® bracket later on. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 52: Parts Description And Connections

    10 Parts Description and Connections IR LEDs IR LEDs Ambient light sensor Zoom lens COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 53 Important information on the earthing/grounding connection can be found in the section “Earthing/Grounding” on page 18. Detailed pinout information can be found in the chapter “Pin Assign- ment” on page 54. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 54: Pin Assignment

    Audio In GND Audio black Alarm Out 1 orange Alarm Inputs For use with potential-free switch contacts. Alarm Relay Outputs Max. 30 V DC, 1 A; no AC. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 55 +48 V DC Camera black / ③ not used black / ④ not used black / Functional Earth green-yellow Fig. 35: Power cable (5-core, HARTING plug on multi-stranded wires with wire-end ferrules) COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 56: Configuration

    Microsoft Internet Explorer*) 11 (Windows 7) Microsoft Edge*) (Windows 10) Google*) Chrome*) Mozilla*) Firefox*) (latest available version of each browser) Browser settings JavaScript*) enabled Sound Sound card or on-board sound chip (min. 16 bit) COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 57: Establishing The Connection

    The connection to the device is then established. After the successful connection to the device and before the very first login, a system security dialog for the first-time access is displayed. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 58: First-Time Access

    ➡ Enter a new password for the default administrator account and confirm your input (the strength of the selected password is displayed during input). ➡ Click “OK”. After the first successful access to the device, the login dialog is displayed. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 59: Login

    ➡ Configure all required settings. ➡ Finally, click “LOGOUT” to properly log out of the device. Detailed descriptions of the configuration settings can be found in separate documentations that are available on www.dallmeier.com. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 60: Limits Of The System

    (wide end of the zoom range), parts of the camera body may be- come visible in the outer image areas. This is due to the lens design and does not constitute a defect. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 62: Technical Product Specification (Basic Data)

    Audio Line Out Impedance: 600 Ω Infrared (IR) Illumination Range Up to 200 m Beam angle Adjustable by zoom level Additional Features ✓ Ambient light sensor Mechanically removable ✓ infrared(IR)-cut filter COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 63 Approx. 16.2 kg (35.7 lb) Environmental Conditions Suitable Indoor and outdoor installation sites Operating temperature −30 °C to +65 °C (−22 °F to 149 °F) Relative humidity 0% – 90% RH, non-condensing COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 64 The technical product specification (basic data) in this document is based on the information at the time of this document’s compilation. Detailed information and possible updates can be found in the currently valid product specification on www.dallmeier.com. COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...

  • Page 65: Dimensions

    15 Dimensions 303 mm (11.93") Fig. 36 COMMISSIONING – DDZ5000HD-DN/IR Series | REV. 1.0.1 | © 2019 Dallmeier...
  • Page 68 HEAD & ACCOUNTS OFFICE Dallmeier electronic GmbH & Co.KG Bahnhofstr. 16 93047 Regensburg Germany +49 941 8700-0 +49 941 8700-180 mail info@dallmeier.com www.dallmeier.com...

This manual is also suitable for:

Ddz5236hd-dn/irDdz5436hd-dn/ir
