Terminal/
Function
[factory setting]
Designation
25
DIN2
Digital input 2
[I/O DeviceNet DIN2]
26
DIN4
Digital input 4
[I/O DeviceNet DIN4]
Reference potential
27
GND
for digital signals
28
29
24V
External 24V supply
30
31
24V o
External 24V supply
for the DOs
32
GND o
Reference potential
for digital signals
33
DO1
Digital output 1
[I/O DeviceNet DO1]
34
DO2
Digital output 2
[I/O DeviceNet DO2]
35
GND o
Reference potential
for digital signals
36
Details of M12 connections of the SK TU4-DEV-M12
The special wiring of the M12 round plug connector
enables the connection of both single and double
sensors, which are equipped with normal M12 system
connectors
in
configuration.
With the use of M12 round plug connectors, the terminal
bar connectors for the digital inputs (Terminals 19, 20,
25, 26) must not be used.
BU 0280 GB
Data
Low 0V ... 5V
High 15V ... 30V
= 8.1k 
R
i
Input capacitance 10nF
Scan rate 1 ms
Inputs as per EN 61131-2
Type 1
As for terminal 11
24VDC -/+20%
Up to 1A, according to
load
reverse polarity protected
Low = 0V
High: 24V
Rated current: 500mA
each
the
standard
sensor/actuator
Subject to technical amendments
Description / wiring suggestion
Each digital input has a reaction
time of 1ms.
External supply voltage for system
bus and digital inputs (DIN1 to
DIN4)
Potential isolation
External supply voltage for digital
outputs (DO1 and DO2)
If necessary, bridge to 24V terminal
External supply voltage for digital
outputs (DO1 and DO2)
If necessary, bridge to GND
terminal
The digital outputs should be used
with a separate 24V supply
External supply voltage for digital
outputs (DO1 and DO2)
If necessary, bridge to GND
terminal
2 Assembly and installation
Parameter
P174
P174
-
-
-
-
P150
P175
P150
P175
-
