  • Page 1 Copyright Copyright 1997 by ICP DAS. All rights are reserved. Trademark The names used for identification only may be registered trademarks of their respective companies. I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------1...

  • Page 2: Table Of Contents

    Terminal Resistance Setting ............8 Wire Connection ................10 Network Deployment ................11 Definition ..................11 Driving Capability ................ 11 Fiber Selection & Fiber Length...........12 Baud and Bus Length..............13 Dimension .....................14 I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------2...

  • Page 3: Introduction

    CAN bus signal to fiber optic cables. The fiber length between two I-2532s can be up to 1.4km (4593ft), it is mainly decided by the cable attenuation of fiber and the CAN bus baud. I-2532 is the economic solution for applications which require protecting the data transmission from electrical exposure, surges, lightning or chemical corrosion.

  • Page 4: Features

    ESD ： +/- 4KV Contact Discharge EFT ： +/- 1KV Surge ： +/- 2KV 1.3 Applications Factory Automation Building Automation Home Automation Vehicle Automation Control system Monitor system … I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------4...

  • Page 5: Technical Data

    ISO 11898-2 CAN_H Ω Physical CAN layer Fiber Driver CAN_L Photo Isolation Power Regulator Block Diagram of I-2532 Power Port +10V ~ +30V Figure 2-1 Block Diagram of I-2532 I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------5...

  • Page 6: Appearance

    CAN Port CAN_L T.R. active CAN_H T.R. CAN_GND inactive ISO 11898-2 standard Power Port Terminal Resistance Switch +10 ~ +30V between GND and +VS Figure 2-2 Appearance of I-2532 I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------6...

  • Page 7: Pin Assignment

    Therefore, connecting the F.G correctly can enhance the capability of the ESD protection and improve the module’s reliability. Wiring of CAN_GND and F.G. is not necessary; users can modify the configuration of wiring according to real applications. I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------7...

  • Page 8: Led Indicator

    +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 2.4 LED Indicator When the I-2532 is active, the POWER LED will display with red light. Transmitting/receiving one message to/from fiber cable will flash the TD/RD LED once. The TD/RD LED may always be turned on if there are a lot of messages transmitted on fiber cable.
  • Page 9 Case1: R = 120Ω Case2: R = 180Ω CAN_H CAN_H CAN_L CAN_L Case3: R = 180Ω, R = 120Ω CAN_H Fiber CAN_L I-2532 I-2532 Figure 2-5 Terminal Resistance I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------9...

  • Page 10: Wire Connection

    (ISO 11898-2) Figure 2-6 Wire Connection of I-2532 The I-2532 has a metallic board attached to the back of the plastic basket. This metallic board and the F.G. pin of power connector are interconnected inside the I-2532. When users mount the I-2532 onto a metal DIN rail, users can connect the DIN rail to Earth Ground to replace connecting the F.G.

  • Page 11: Network Deployment

    Table 3-1 Recommended DC parameters for CAN Bus Line Wire Cross-Section [mm Resistance [ /km] ~0.25 (AWG23) < 90 ~0.5 (AWG20) < 50 ~0.8 (AWG18) < 33 ~1.3 (AWG16) < 20 I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------11...

  • Page 12: Fiber Selection & Fiber Length

    ~1.3 (AWG16) < 980 < 900 < 780 < 670 3.3 Fiber Selection & Fiber Length The specification of fiber used to connect I-2532 is shown as following table. Table 3-3 Specification of Fiber Diameter [ m] Operating Type (Core/Cladding)

  • Page 13: Baud And Bus Length

    I-2532 Figure 3-2 Segment Length and Bus Length When users add one pair of I-2532 into a CAN bus system, the ideal bus length will reduce 50 meters because the propagation delay of one I-2532 is equal to the propagation delay caused by 25 meters bus length. For example, if users use baud 50Kbps and add two I-2532s into a CAN bus system, the ideal bus length should less than 950 meters (1000-25*2=950).

  • Page 14: Dimension

    +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 4 Dimension 77.5 32.3 Left Side View Right Side View Front Side View Unit: mm 88.0 92.0 Back View Top View Bottom View Figure 4-1 Dimension of I-2532 I-2532 CAN to Fiber Converter User Manual (ver. 1.1, 2008/10/03) ------14...
