Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017
Supplemental Material For 15kV VCP-W
15kV VCP-W
Interactive Instructions
This is a user interactive supplemental booklet. This material is
intended to enhance the technical information included in
the instruction booklet for the 15kV VCP-W circuit breaker
manufactured by Eaton.
Supplemental Material
For 15kV Element
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Eaton 150VCP-W Series
Summary of Contents for Eaton 150VCP-W Series
- Page 1 Supplemental Material For 15kV VCP-W This is a user interactive supplemental booklet. This material is intended to enhance the technical information included in the instruction booklet for the 15kV VCP-W circuit breaker manufactured by Eaton. Supplemental Material For 15kV Element...
- Page 2 Circuit breakers are equipped with safety • interlocks. Do not defeat them. This may result in death, bodily injury or equipment damage. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 3 It is visible when the circuit breaker is withdrawn and is viewed from the rear of the circuit breaker. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 4 5 kV 20 kV RECOMMENDED THAT ALL OPERATING PERSONNEL STAND AT LEAST ONE METER AWAY IN FRONT OF THE CIRCUIT 7.5 kV / 15 kV 27 kV BREAKER. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 5 AND/OR BELOW NORMAL CONTACT SPACING, IT IS RECOMMENDED THAT ALL OPERATING PERSONNEL STAND AT LEAST ONE METER AWAY IN FRONT OF THE CIRCUIT BREAKER. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 6 0.000 5. Provide control power to the DLRO and turn it to the ON position. Select 100A output, if adjustable. conversion Field EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 7 It may be necessary to use a small mirror and flashlight to clearly see the “T” shape indicator. The figure below shows the procedure for determining the contact wipe of each spring type. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 8 After the oil has been drawn off, the bearings should be packed with Eaton Grease 53702AM or equivalent. Proper Lubrication Times Per Rating RATINGS OPERATIONS 29kA and below Above 29kA 3000 Amp EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 9 48Vdc 699B196G03 (QUICK DISCONNECT) 125Vdc / 120Vac 699B196G01 250Vdc / 240Vac 699B196G02 SPRING CHARGING MOTOR 48Vdc 699B196G06 (RING TERMINALS) 125Vdc / 120Vac 699B196G04 250Vdc / 240Vac 699B196G05 EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 10 . Install tie wraps to hold wire bundle. (RING TERMINALS) 48Vdc 3759A76G11 Mechanically and electrically test the circuit breaker and 125Vdc / 120Vac 3759A76G12 hipot the secondary wiring. 250Vdc / 240Vac 3759A76G13 EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 11 694C636G01 components. 125Vdc / 120Vac 694C636G02 250Vdc / 240Vac 694C636G03 SHUNT TRIP KIT (RING TERMINALS) 24Vdc 8794C81G14 48Vdc 8794C81G11 125Vdc / 120Vac 8794C81G12 250Vdc / 240Vac 8794C81G13 EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 12 250Vdc 8794C81G03 yoke by the magnetic force, even though the reset 120Vac 8794C81G04 lever has moved up. 240Vac 8794C81G05 EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 13 If during an electrical charging operation the camshaft fails to rotate far enough for the motor cutoff switches to actuate, the charging pawls may require adjustment. EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 14 Visually inspect that the counter changes state during operations. Adjusting the operations counter on a 150VCP-W25 mechanism. Replacement Parts ITEMS DESCRIPTION EATON STYLE NUMBER VEEDER COUNTER VEEDER COUNTER 592C040H01 OPERATOR LINK 8864A37H01 EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 15 Date # of Breaker Operations CloSure Distance the instruction manual. ” to ” * Note: Use the center of the marker diameter to determine "X" distance EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
- Page 16 VCP-W Circuit Breaker Model VCP-W 5/15 63kA 3000A EATON | Visual Instruction Booklet Essentials | 150VCP-W 25kA 1200A | January 2017...
