Linear Technology DC2183A Demo Manual page 10

ITEM QTY REFERENCE
DC2183A-A Required Circuit Components
1 1 DC2183A
2 1 C8
3 2 C9,C10
4 1 L1
5 2 R13,R19
6 0 R26,R28
7 2 R27,R32
8 1 R33
9 1 U1
DC2183A-B Required Circuit Components
1 1 DC2183A
2 1 C8
3 2 C9,C10
4 1 L1
5 2 R13,R19
6 2 R26,R28
7 2 R27,R32
8 1 R33
9 1 U1
DEMO MANUAL DC2183A
PART DESCRIPTION
DC2183A General BOM
CAP., NP0, 4.7pF, 50V ± 0.25pF, 0402
CAP., NP0, 8.2pF, 50V ± 0.25pF 0402
INDUCTOR, CERAMIC CHIP, 56nH, 2%, 0603
RES., CHIP, 15Ω, 1/20W, 5% 0201
RES., CHIP, OPT, 0402
RES., CHIP, 86.6, 1/10W, 1% 0603
RES., CHIP, 86.6, 1/16W, 1% 0402
ADC, 16 BIT, 210 Msps, QFN
DC2183A General BOM
CAP., NP0, 12pF, 50V 5% 0402
CAP., NP0, 3.9pF, 50V ± 0.25pF 0402
INDUCTOR, CERAMIC CHIP, 18nH, 2%, 0603
RES., CHIP, 10Ω, 1/20W, 5% 0201
RES., CHIP, 68.1Ω, 1/16W, 1% 0402
RES., CHIP, 43.2, 1/10W, 1% 0603
RES., CHIP, 105Ω, 1/16W, 1% 0402
ADC, 16 BIT, 210 Msps, QFN
MANUFACTURER/PART NUMBER
TDK, C1005C0G1H4R7C
TDK, C1005C0G1H8R2C
MURATA, LQP18MN56NG02D
VISHAY, CRCW020115R0JNED
OPTION
VISHAY, CRCW060386R6FKEA
VISHAY, CRCW040286R6FKED
LINEAR TECH., LTC2107IUK#PBF
MURATA, GRM1555C1H120JA01D
TDK, C1005C0G1H3R9C
MURATA, LQP18MN18NG02D
VISHAY, CRCW020110R0JNED
VISHAY, CRCW040268R1FKED
VISHAY, CRCW060343R2FKEA
VISHAY, CRCW0402105RFKED
LINEAR TECH., LTC2107IUK#PBF
