- Page 1 SET-UP INSTRUCTIONS WP240 / WP270 Firewood Processor EMB Manufacturing Inc. 4144 Boomer Line · St. Clements, ON · N0B 2M0 · Canada www.wallensteinequipment.com PRINTED IN CANADA Part Number: Z97115_SI-WP240-270_July-2018 Rev Aug-2018...
- Page 2 WP240-270 Set-up Instructions Always Put Safety First! WARNING! Position the crate in a large open area to allow access from all sides during assembly. Stay clear of overhead power lines and obstructions when lifting the machine during assembly. Contact with power lines can cause Read these assembly instructions thoroughly electrocution.
- Page 3 WP240 / WP270 Set-up Instructions WP240 / WP270 Set-up Instructions IMPORTANT! Inspect for damage from NOTE: Crate top and some parts are attached to shipping. Immediately contact the skid with screws. shipping company if damage is found.
- Page 4 WP240 / WP270 Set-up Instructions NOTE: Shipping brackets and hardware not reused. A. Bottom Chute B. Lead In Chute NOTE: WP270 is shown. WP270 and WP240 are similiar. C. Log Chute D. Splitter Chute E. Winch Strap Hardware is located inside Operators Manual Tube.
- Page 5 WP240 / WP270 Set-up Instructions...
- Page 6 WP240 / WP270 Set-up Instructions...
- Page 7 WP240 / WP270 Set-up Instructions WP240 / WP270 Set-up Instructions...
- Page 8 WP240 / WP270 Set-up Instructions WP240 / WP270 Set-up Instructions...
- Page 9 WP240 / WP270 Set-up Instructions Pre-delivery Inspection Inspect for damage from shipping. Immediately contact the shipping company if damage is found. Wood Processor Hydraulic Splitter Controls Function Hydraulic Cylinder Functions Splitter Chute Folds Up Wedge Height Adjuster Functions Loader and Lead-in Chutes Fold Up and Latch Securely...
-
Page 10: Bolt Torque Specifications
WP240-270 Set-up Instructions Bolt Torque Specifications Checking Bolt Torque Imperial Bolt Torque Specifi cations The tables shown give correct torque Torque Value values for various bolts and capscrews. Bolt SAE Gr. 2 SAE Gr. 5 SAE Gr. 8 Diameter Tighten all bolts to the torque values lbf•ft... -
Page 11: Hydraulic Fitting Torque
WP240-270 Set-up Instructions Hydraulic Fitting Hydraulic Fitting Torque Torque Tube Size Flats From Size Torque value Tightening Flare Type Tube Fittings Across Finger Tight Flats 1. Check flare and flare seat for defects that lbf•ft Inches Inches N•m Flats Turns might cause leakage. - Page 12 EMB Manufacturing Inc. 4144 Boomer Line · St. Clements, ON · N0B 2M0 · Canada www.wallensteinequipment.com...
