Spectra T200 Fan Replacement Instructions page 9

Replacing the Fan Assembly
3. Using your fingers or a #2 Phillips screwdriver, loosen the two knurled
4. Lift the front panel upward and away from the chassis to disengage the
November 2013
screws securing the bottom of the library front panel to the chassis.
Figure 3 Front panel screws.
two nuts on the back of the front panel from the holes on either side of
the chassis. Set the cover aside.
Lift up and away
Library Front
Figure 4 Front panel removal.
Spectra T200, T380, T680, T950 and T-Finity libraries
Replacing a T200, T380, or T680 Fan Assembly
Library Front
Knurled
screws
Alignment nut
on front panel
9
