A200 EH QUICK REFERENCE GUIDE
The quick reference guide is not a substitute for the Operators Manual!
Please refer to Operators Manual for more detailed information
TRACTOR CONNECTION
1. Hydraulics
Red pipe
> Supply (25-35lpm)
Blue pipe
> Return (Free flow return!!)
2. Electrics
A. Connect 12V supply to 3pin plug
B. Connect wrapper harness to controller
C. Connect receiver to controller
D. The controller can then be mounted in the
tractor cab.
ENTERING THE WORKING MODE
1. Adjust the position of the dispenser to
ensure that the film will be applied to the
centre of the bale.
2. Install the bale matt.
3. Add the film roll into the dispenser, ensuring
that the film is threaded correctly, and
attach the film to the Cut & Start.
2
A
B
1
3

Advertisement

loading
Need help?

Need help?

Do you have a question about the A200 EH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tanco A200 EH

  • Page 1 A200 EH QUICK REFERENCE GUIDE The quick reference guide is not a substitute for the Operators Manual! Please refer to Operators Manual for more detailed information TRACTOR CONNECTION 1. Hydraulics Red pipe > Supply (25-35lpm) Blue pipe > Return (Free flow return!!) 2.
  • Page 2 Emergency Stop R6 – Start Automatic cycle L6 – Select Operating Mode: „M“ or „A“ RF REMOTE OPERATION The RF (Radio Frequency) remote is required to operate the A200 EH wrapper remotely from the loader tractor. RF Receiver Auto Start wrap...
  • Page 3 RF REMOTE OPERATION Syncing RF Remote with controller receiver If a new remote-control kit is being fitted, or if the battery has been replaced in the remote, the controller must be set to receive the unique frequency of the sender unit: Ensure ‘RF’...
