RC SERIES ENGINEERING GUIDE
Dimensional Data - Slope Top Cabinet
RCS09-18
Overall Cabinet
Slope Top
A
B
Configuration
Width Depth Height Grille Lid
in.
45.0 11.1
28.6
09-12
cm.
114.3 28.2
72.6
in.
50.0 12.6
29.1
15-18
cm.
127.0 32.0
73.9
C
D
E
F
Grille
Grille
Length
Width
9.2
35.0
6.1
23.4
88.9
15.6
9.2
35.0
6.1
23.4
88.9
15.6
24
G
H
I
J
2.8
44.1 10.3
4.3
7.2 112.0 26.0 10.9
2.5
49.1 11.8
4.3
6.4 124.7 29.8 10.9
