- Page 1 Assembly Instructions Item#: D-GG038PST Questions, problems, missing parts? call our customer service department at 1-866-578-6569 from 8:00 am EST to 8:00 pm PST, or email to customer.care@sunjoygroup.com...
-
Page 2: Package Contents
PACKAGE CONTENTS U1 U2... - Page 3 PACKAGE CONTENTS LABEL DESCRIPTION PART# GG0038XXX01 Pole (1) GG0038XXX02 Pole (2) Base GG0038XXX03 GG0038XXX04 Base cover GG0038XXX05 Long screen Short screen GG0038XXX06 GG0038XXX07 Beam connector (middle) GG0038XXX08 Beam connector (corner) (1) Beam connector (corner) (2) GG0038XXX09 GG0038XXX10 Small top frame GG0038XXX11 Corner top beam GG0038XXX12...
-
Page 4: Hardware Contents
HARDWARE CONTENTS Φ8×180 M6×15 M6 Washer M6×25 M6×15 M6×60 M6 Nut M6×30 M6 Nut with cap Bolt Hex bolt Hex Bolt Bolt bolt Stake Wrench DD08180C W10D XM06QC BM06015C LM06C SM06030C SM06015C UD06C BM06025C SM06060C Qty. 88 Qty. 189 Qty. 16 Qty. - Page 5 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. Estimated Assembly Time: 90 minutes Tools Required for Assembly: Wrench (included) and Phillips Screwdriver (not included) ASSEMBLY INSTRUCTIONS...
- Page 6 ASSEMBLY INSTRUCTIONS 2. Connect the long screen (D) and short screen (E) to the pole (A1 and A2), securing with bolts (CC) and washers (BB). Hardware Used M6 Washer x 16 M6x25 Hex bolt x 16 3. Attach the beam connector (corner) (2) (G2) to the top of pole (A2), securing with blots (DD) and washers (BB).
- Page 7 ASSEMBLY INSTRUCTIONS Fig. 13 Fig. 14 Fig. 6 Fig. 7 Fig. 5 Fig. 8 Fig. 10 Fig. 9 Fig. 12 Fig. 11 5&6. Connect the corner top beam (I) to the beam connector (corner) (G1 and G2), securing them with bolts (EE), washers (BB) and nuts (FF). Connect the other end of corner top beam (I) to the small top frame (H).
- Page 8 ASSEMBLY INSTRUCTIONS 7&8. Connect the middle top beam (J) to the small top frame (H) by bolts (EE), washers (BB) and nuts (FF). Connect the other end of the middle top beam (J) to the beam connector (middle) (F). Hardware Used M6 Washer M6x60 Bolt M6 Nut...
- Page 9 ASSEMBLY INSTRUCTIONS 11&12. Connect the long side beam (N5) to the corner top beam (I), securing them with bolts (AA), washers (BB). Connect the other end of long side beam (N5) to the middle top beam (J). Repeat this procedure for long and short beam (N6, O1, O2, O3).
- Page 10 ASSEMBLY INSTRUCTIONS Fig. 18 Fig. 17 Fig. 16 Fig. 15 Fig. 20 Fig. 21 Fig. 19 Fig. 22 15. Connect the long and small roof panel (M1) to the short and Small roof panel (M2), securing them with bolts (AA), washers (BB). Hardware Used M6x15 Bolt M6 Washer...
- Page 11 ASSEMBLY INSTRUCTIONS 16. Secure the covering of small top (U1&U2) by using bolts (GG) and washers (BB); secure the small top cap (V) by using nuts (HH) and washers (BB). BB GG Hardware Used M6 Washer M6x30 Bolt M6 Nut with cap Hardware Used 17.
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE To extend the life of grill gazebo, do not use when there are high winds. Disassemble and pack away when the gazebo will not be used for an extended period. Ensure that the canopies and metal parts are all dry before packing away. ONE YEAR LIMITED WARRANTY This limited warranty is extended to the original purchaser and applies to defects in material and workmanship of your item provided the item is maintained with care and used only for personal,... - Page 15 REPLACEMENT PARTS LIST LABEL DESCRIPTION PART# GG0038XXX01 Pole (1) GG0038XXX02 Pole (2) GG0038XXX03 Base GG0038XXX04 Base cover GG0038XXX05 Long screen GG0038XXX06 Short screen GG0038XXX07 Beam connector (middle) GG0038XXX08 Beam connector (corner) (1) GG0038XXX09 Beam connector (corner) (2) Small top frame GG0038XXX10 GG0038XXX11 Corner top beam...
