- Page 1 Woodcreek 4-in-1 Pellet Grill ASSEMBLY IN STRUC TIONS Model SMK0036AS / SMK0036ASO...
- Page 2 READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT. The following tools are required to assemble this Cuisinart Woodcreek 4-in-1 Pellet Grill: • Phillips Screwdriver • Pliers or Wrench...
- Page 4 Step 1 • Remove 2 screws • Attach FRONT PANELS • Tighten 2 screws Step 2 • Loosen 6 screws 3-4 turns on FRONT LEGS • Do not remove screws • Attach FRONT PANELS using keyholes • Tighten 6 screws NOTE: Before tightening keyhole screws, make sure panels are aligned.
- Page 5 Step 3 • Loosen 3 screws • Attach RIGHT SIDE PANEL • Tighten 3 screws on RIGHT SIDE PANEL Step 4 • Loosen 2 screws • Attach LEFT SIDE PANEL • Tighten 2 screws on LEFT SIDE PANEL...
-
Page 6: Table Of Contents
Step 5 • Loosen 2 screws • Attach CART BRACE • Tighten 2 screws on CART BRACE • Remove 4 screws Remove 2 screws Remove 2 screws Step 6 • Attach CART BASE • Tighten 4 screws (Removed from Step 5) - Page 7 Step 7 • Loosen 8 screws on REAR LEGS • Attach BACK PANEL to REAR LEGS • Tighten 4 screws • Remove 4 screws Remove 2 screws Remove 2 screws Step 8 • Attach CART BASE rear legs • Tighten 4 screws (Removed from Step 7)
-
Page 8: Step 10
Step 9 • Attach LEFT SIDE PANEL and CART BRACE • Tighten 4 screws Tighten 4 screws Step 10 • Lock CASTERS • Attach CASTERS legs CASTERS unlocked locked... -
Page 9: Cart Brace
ACCESSORY Step 11 HOOKS • Attach ACCESSORY HOOKS to LEFT SIDE PANEL CART BRACE with wing nuts Step 12 • Loosen 1 screw • Remove 2 screws Remove 2 screws Loosen 1 screw... -
Page 10: Step 13
Step 13 • Loosen 5 screws • Remove 2 screws Loosen 5 screws Remove 2 screws Step 14 • Set GRILL BODY cart • Make sure screw drops into rear cart brackets • Push GRILL BODY back of cart • Install 2 screws in FRONT BRACKETS (Removed from Step 12... - Page 11 Step 15 • Remove 4 screws from GREASE CUP BRACKETS • Install GREASE CUP BRACKETS to the bottom of the GRILL BODY using 4 screws Step 16 • Remove 2 screws • Attach GREASE CHANNEL • Tighten 2 screws...
- Page 12 Step 17 • Loosen 2 screws • Attach LEFT SIDE CONTROL PANEL LEFT SIDE TABLE over keyholes • Tighten 2 screws • Remove 1 screw and washer Loosen screws Remove screw and washer Step 18 • Attach LEFT SIDE TABLE to GRILL BODY using keyholes...
- Page 13 Step 19 • Install screw and washer (Removed from Step 17) • Make sure control panels are aligned • Tighten 5 screws from Step 18 and Step 19 Align Panels Step 20 Remove screw • Remove 1 screw • Loosen 2 screws Loosen 2 •...
- Page 14 Step 21 • Attach PELLET HOPPER to GRILL BODY • Tighten 4 screws (Find M6x35 screws bag with owners manual) Align Panels Step 22 • Install 2 screws (1 screw removed in Step 12 and 1 screw removed in Step Install 2 screws...
- Page 15 Step 23 • Install PELLET HOPPER LID HANDLE (screws, washers and bezels are pre-installed in handle) Step 24 • Install TEMPERATURE GAUGE and BEZEL using washer and wing nut...
- Page 16 Step 25 • Install HOOD HANDLE (Wing nuts, bezels and washers are pre-installed on handle) Step 26 Loosen screw • Remove 4 screws and washers • Loosen 1 screw Remove 4 screws and washers...
- Page 17 Step 27 • Install AUGER HOUSING using keyhole in fi rebox and slots in pellet hopper bracket • Tighten 5 screws and washers in fi rebox Step 28 • Remove 2 screws • Attach CORD WRAP using 2 screws...
- Page 18 Step 29a • Connect wiring for Controller and Pellet Sensor • These wires can only be connected one way • Make sure the connectors are lined up properly before tightening Step 29b • Once connected, twist to tighten Step 29c •...
- Page 19 Step 30 • Attach CONTROL KNOB to controller Step 31 • Attach HEAT BAFFLE...
- Page 20 Step 32 • Install LEFT HEAT PLATE on welded brackets Note: The 2 longer feet go on the left side of the fi rebox Step 33 • Install RIGHT HEAT PLATE on welded brackets Note: The angled lip should face left...
- Page 21 Step 34 WARMING RACK • Install COOKING GRATES WARMING RACK COOKING GRATES Step 35 • Install ASH CATCHER and GREASE CUP GREASE CATCHER...
- Page 22 Step 36 • Store GRIDDLE ACCESSORY HOOKS Step 37 • Store CERAMIC INSERT and CHARCOAL INSERT ACCESSORY HOOKS...
- Page 23 Model SMK0036AS / SMK0036AS0 Assembled ©2019 The Boltz Group LLC OM0036AS/ASO Assembly Instructions for Models Carrollton, Texas 75006 U.S.A. 1019 SMK0036AS / SMK0036ASO...
