Original Instructions
Originalinstruktioner
Technický popis
DX 20 / DX 30 / DX 20+ / DX 30+
SPREADER
PLEASE READ CAREFULLY BEFORE USING THE MACHINE
LÄS NOGA INNAN DU ANVÄNDER MASKINEN
PŘED POUŽITÍM STROJE PEČLIVĚ PROSTUDUJTE
Réf: 400 848-04 EN-SV
Les Portes de Bretagne
P.A. de la Gaultière – 35220 CHATEAUBOURG France
Tél :(33)02-99-00-84-84 · Fax : (33)02-99-62-39-38
Site Internet : www.sulky-burel.com
E-Mail : info@sulky-burel.com
Adresse postale
SULKY-BUREL – CS 20005 – 35538 NOYAL SUR VILAINE CEDEX France
17/05/2018
