Removing the 8510T Terminal Stand
After you have disconnected the cords, follow these directions for
removing the desktop stand from the bottom of the terminal.
Place the terminal face down on a flat surface. The Bar Code label
1
on the bottom of the set should be toward you.
Remove the screw on the lower center of the stand. See Figure 2
2
for the location of the screw.
Remove the desktop stand attached to the base of the terminal by
3
tabs on the top and bottom of the stand. See Figure 2.
Slowly rotate the bottom of the desktop stand up toward the top
of the terminal.
Then carefully lift the upper tab on the top of the stand out of the
upper tab slot.
