Powerlink

11 Powerlink

®
UNIGATE IC-Powerlink serves to adapt a serial interface to Powerlink CN (Controlled Nodes).
The end device's protocol is being converted in the UNIGATE
11.1

Data exchange mode

The gateway has to be in the data exchange mode, so that a data exchange between the RS-
side of the gateway and the fieldbus is possible. This mode is always avtive as long as the gate-
way is not in the configuration mode, the firmware update- or Debugmode. In the data exchange
mode the gateway will carry out the downloaded Script.
11.2

Powerlink address-assignment

The Powerlink address can either be assigned through WINGATE or the Script.
11.3

Project planning

Use any project planning tool for project planning.
A sample XDD-file can be found on the Internet (www.deutschmann.com) free of charge. Gener-
ating the XDD-file is also provided as service from Deutschmann Automation.
11.4

Possible data lengths

In der folgenden Tabelle sind die maximal zu übertragenden Daten tabellarisch dargestellt:
Nachricht
Rx PDO
Tx PDO
SDO
11.5

Literature

We recommend to check out the website www.ethernet-powerlink.org to help you quickly get to
grips with the subject of Powerlink.
34
Anzahl Nachrichten
1
1
max. 256 Stück
Instruction manual UNIGATE
Deutschmann Automation GmbH & Co. KG
®
via a Script.
Nachrichtenlänge
max. 1514 Bytes
max. 1514 Bytes
max. Variablenlänge pro SDO = 256 Bytes
®
IC - Powerlink V. 2.3 21.4.15
