Microtek ScanMaker 1000XL Start Here Manual page 2

Step 3:
A. Remove the yellow "Step 3" sticker from your scanner.
B. With the scanner power off, tilt the front right corner of
the scanner to see the locking screw at the bottom.
C. Using a screwdriver, push and turn the locking screw
counterclockwise to the unlock position. When successfully
unlocked, the screw will push out a little, protruding
slightly from the bottom of the scanner.
NOTE: To lock the scanner (for shipping and other reasons), refer to the
ScanMaker 1000XL User Guide.
Step 4:
To the power adapter
A. Remove the yellow "Step 4" sticker from your
scanner.
B. Connect the power cord to the back of the
scanner.
C. Plug the power cord into a power source.
To the Hi-Speed USB cable
D. Connect one end of the cable to your computer.
E. Connect the other end of the cable to the
scanner.
F. Press the power switch at the back of your
scanner, and wait for the indicator light on the
front panel to stop blinking and stay on steady.
The system will detect your scanner
automatically.
Unlock Scanner
Connect Scanner
F
B
NOTE: If your computer has both Hi-Speed USB (USB 2.0) and USB
1.1 ports, connect the cable to the Hi-Speed USB port. Use the USB
1.1 port only if your computer does not have Hi-Speed USB.
For details on how to connect using the alternate
FireWire connection, refer to the ScanMaker 1000XL
User Guide.
2
D
E
C
