USE AND CARE GUIDE
60in Media Console Infrared Electric Fireplace in Cherry
IMPORTANT INSTRUCTIONS
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE
WARNING!
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this
fireplace . We strive to continually create quality products designed to enhance your home. Visit us online
to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection BSF-1733
Summary of Contents for Home Decorators Collection BSF-1733
- Page 1 We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace . We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
-
Page 2: Table Of Contents
Table of Contents Package Contents ....Table of Contents....Assembly . -
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to operate or install the product. To avoid malfunction, please be certain the input voltage of the electric fireplace insert and the voltage of the outlet are identical before plugging in. Check the unit for any damage that may exist (such as missing screw, dents, etc.) before using this device. - Page 4 Safety Information (continued) DO NOT operate this device if the cord becomes damaged, after the unit malfunctions in any way, has been dropped or becomes damaged in any manner. If this happens, discard the unit or return to an authorized service facility for inspection and/or repair. DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock, fire or damage to this fireplace.
-
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 45 minutes TOOLS REQUIRED Phillips screwdriver (Not provided) -
Page 6: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS PART PART DESCRIPTION QUANTITY DESCRIPTION QUANTITY Right Partition Base Rail Big Shelf Small Shelf Top Back Panel Door Bottom Back Panel Electric Fireplace Insert Upper Side Panel Remote Control Lower Side Panel Battery Left Partition... -
Page 7: Assembly
Assembly Installing the rail and partition With assistance from other adults, place the Right partition (I) upside down on a soft and smooth surface. Align the holes on the Rail (J) and the punctures on the Right partition (I) and push together until flush. - Page 8 Assembly (continued) Attaching the lower side panel With assistance from other adults, place the Lower side panel(G) on a smooth and soft surface with the smooth end on top. Insert the wooden tenons into the corresponding holes of the Big shelf (C). Slightly move parts to ensure the holes of the Lower side panel (G) and the holes of the Big shelf (C) align.
- Page 9 Assembly (continued) Attaching the upper side panel With assistance from other adults, insert the wooden tenons of the Upper side panel (F) into the corresponding holes of the Big shelf (C). Slightly move parts to ensure the holes of the Upper side panel (F) and the holes of the Big shelf (C) align.
- Page 10 Assembly (continued) Attaching the small shelf Place the Shelf pins (JJ) into the holes of the Lower side panel (G) and Left and Right partition (H&I) at the middle row. (You may choose the upper or lower row according to your needs, but the height of both Small shelves (K) should be consistent).
- Page 11 Assembly (continued) Installing the back panel Attach the Top back panel (D) and Bottom back panel (E) to the back of the mantel by using Round head screws (GG) and a screwdriver (not provided). Make sure the smooth side of the back panels face the front of the fireplace.
- Page 12 Assembly (continued) Attaching the knob With assistance from other adults, support the Door (L). Attach the Knob (FF) onto the Door (L) with Small bolts (EE) using a screwdriver (not provided) and tighten all bolts. Attaching the door With assistance from other adults, align the holes on the Door hinges (LL) with the punctures on the Lower side panel (G).
- Page 13 Assembly (continued) Attaching the electric fireplace insert Place the Electric fireplace insert (M) into the mantel from the back and gently push forward to the proper position and place it at the center. Attach the Electric fireplace insert (M) with Bracket (KK) and Round head screw (HH) using a screwdriver (not provided).
-
Page 14: Operation
Operation Control Panel on electric fireplace insert (M) Remote Control (N) WARNING-The fireplace must be properly installed before it is used. < > Turns the flame and logs On/Off. < or BRIGHTNESS> Controls the brightness of the flame and logs. <HEAT>... -
Page 15: Care And Maintenance
Operation (continued) Other Important Features Children Lock Press and hold the [UP] and [DOWN] buttons on the control panel at the same time for more than 2 seconds to lock the fireplace. This prevents misuse by children and interference by other remote controls of other home devices. Also, the remote control function of this electric fireplace will be locked. -
Page 16: Fcc Information
FCC Information NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 17: Troubleshooting
Troubleshooting If you have any questions regarding the product, please call Home Decorators Collection Customer Service, 1-800-986-3460, 8 a.m. -7 p.m. EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday. Problem Possible Cause Solution Unit is not plugged into a standard Verify unit is plugged into a standard 120-volt outlet. -
Page 18: Service Parts
Service Parts PART PART DESCRIPTION DESCRIPTION Right Partition Base Rail Big Shelf Small Shelf Top Back Panel Door Bottom Back Panel Electric Fireplace Insert Upper Side Panel Remote Control Lower Side Panel Left Partition... - Page 19 HOME DECORATORS COLLECTION Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
