- Page 1 SERVO 45 NOVA PLUS SERVO 45 S SERVO 45 S PLUS SERVO 45 S NOVA SERVO 45 S NOVA PLUS • Plough Ihre / Your / Votre • Masch.Nr. • Fgst.Ident.Nr. Ihre / Your / Votre • Masch.Nr. • Fgst.Ident.Nr.
- Page 2 Dear Farmer You have just made an excellent choice. Naturally we are very happy and wish to congratulate you for having chosen Pöttinger. As your agricultural partner, we offer you quality and efficiency combined with reliable servicing. In order to assess the spare-parts demand for our agricultural machines and to take these demands into consideration when developing new machines, we would ask you to provide us with some details.
- Page 3 InstruCtIons For Dokument ProDuCt DeLIvery ALOIS PÖTTINGER Maschinenfabrik GmbH GEBR. PÖTTINGER GMBH A-4710 Grieskirchen Servicezentrum Tel. (07248) 600 -0 D-86899 Landsberg/Lech, Spöttinger-Straße 24 Telefax (07248) 600-511 Telefon (0 81 91) 92 99-10 / 21 Telefax (0 81 91) 59 656 GEBR.
-
Page 4: Table Of Contents
Table for 965 mm ..............11 Plough body forms ..............37 OPERATION VARIATION Take care driving onto field with SERVO 45 S ......12 SERVO model ................38 Turning the plough over ............12 SERVO NOVA model ..............38 Setting the plough gradient (11) ..........12 SERVO PLUS model .............. -
Page 5: Warning Signs
warning signs CE sign The CE sign, which is affixed by the manufacturer, indicates outwardly that this machine conforms to the engineering guideline regulations and the other relevant EU guidelines. EU Declaration of Conformity (see supplement) By signing the EU Declaration of Conformity, the manufacturer declares that the machine being brought into service complies with all relevant safety and health requirements. -
Page 6: Attaching To The Tractor
aTTaCHing TO THE TraCTOr Preparations on the tractor General Please observe the power range limits of the tractor being used. Wheels - Air pressure in the tractor’s rear tyres when ploughing should be 0.8 bar. - Under difficult operating conditions additional wheel weights can be advantageous. -
Page 7: Hydraulic Connection
aTTaCHing TO THE TraCTOr Hydraulic connection • If the tractor has a single-action servo-valve only, it is absolutely necessary to have an oil return line (T) professionally installed. - Connecting pressure line (1) and oil return line (2). 1 Single-action control unit 1 Double-action control unit + 1 Double-action control unit Preparations on the plough... -
Page 8: Attaching To The Tractor
aTTaCHing TO THE TraCTOr Attaching to the tractor Important advice: Supportstand in the working position Safety advice: 1. Lock the bolt (1) into the hole of the stand plate. See supplement A1, Pt. 8a-h 2. Secure the supportstand with linch pin (K). - Switch tractor’s hydraulics to control position. -
Page 9: Presetting The Plough
PrEsETTing THE PLOUgH Before driving to the field SERVO SERVO NOVA see next page SERVO PLUS SERVO NOVA PLUS 1. Carry out basic setting according to table B, with average cutting width position. 2. Carry out a more accurate setting when in use. Setting both the spindles (ZP, VF) Drawing point (ZP) Backfurrow (VF) -
Page 10: Before Driving To The Field
PrEsETTing THE PLOUgH Before driving to the field SERVO 1. Carry out basic setting according to table C. 2. Carry out a more accurate setting when in use. SERVO NOVA 1. Carry out basic setting according to table A. 2. Carry out a more accurate setting when in use. Set furrow width - Loosen both hexagonal screw (SK). -
Page 11: Fine Setting
PrEsETTing THE PLOUgH Fine setting - Make the measurements (A) and (B) and determine the intersecting point (F) for cat. (825 or 965) in accordance with the table. The measurements (A, B) are each to be made from bolt centre to bolt centre. TD65/92/39 - The position of the intersecting point between the diagonal lines on the graph is the setting (F). -
Page 12: Operation
OPEraTiOn Take care driving onto field with SERVO 45 S Beware! Possible damage when driving onto field with plough still in transport position (horizontal position) and is therefore raised (distance A) - the spindle can become damaged when strong jarring occurs... -
Page 13: Setting The Plough To The Tractor Using "Servomatic
OPEraTiOn Setting the plough to the tractor using "Servomatic" „SERVOMATIC“ enables the optimum adaption of plough to tractor. The following setting controls should be carried out in order. • Never reach into the area where danger of crushing exists as long as parts are still moving. •... -
Page 14: Ploughing With Control Hydraulic
OPEraTiOn Ploughing with control hydraulic So that the hydraulic control functions properly, the following must be observed. - Position upper link (1) so that the attachment point (P1) on the plough during operation is somewhat higher than the attachment point (P2) on the tractor. Pinning the upper link LL, RL = Pinning position for securing TD65/92/27... -
Page 15: Overload Safety
OVErLOaD saFETY Shear bolts The ploughing components are fastened with shear bolts. When overloaded the shear bolts break (30) and the ploughing component swings away and up. - Remove the rest of the shear bolt. - Loosen hexagonal bolt (31). - Swing ploughing component back into the working position. -
Page 16: Servo Nova
sErVO nOVa Fully automatic „Nonstop“ overload safety Nitrogen pressure in the gas accumulator (43) (Factory set) 80 bar The fully automatic overload safety is recommended for soils Pressure adjustment area of the hydraulic cylinder (40) which are difficult to plough e.g. soil with stones or other foreign 90 to 160 bar bodies. -
Page 17: Gas Accumulator (43)
sErVO nOVa Gas accumulator (43) Pressure in the gas accumulator can also be altered. A reduction or increase of gas pressure in the accumulator depends upon the various soil types. • With very light soil the gas pressure can be somewhat reduced. Important! •... -
Page 18: Maintenance And Service
MainTEnanCE anD sErViCE General maintenance advice Cleaning the machine parts Take note! In order to keep the implement in good condition even after a long Do not use a high pressure cleaner to clean bearings or hydraulic service life, please observe the following points: parts. -
Page 19: Setting The Ploughing Component Tilt
MainTEnanCE anD sErViCE Setting the ploughing component tilt If the plough is not penetrating the ground correctly, an improvement can be obtained by turning the eccentric bush. • The blade point in the area „S“ is set either higher or lower depending upon the position of the eccentric bush (A or B). -
Page 20: Additional Devices
aDDiTiOnaL DEViCEs Setting the disk coulter • Set the cutting depth of the disk coulter at a gap of 5 cm to the • The lateral gap to the ploughing blade tip should be 2 - 3 cm. It is ploughing blade tip. -
Page 21: Pre-Ploughing Implements
aDDiTiOnaL DEViCEs Pre-ploughing implements: Maize skimmer, Manure skimmer These implements are designed to incorporate surface trash straw or manure in the soil. • Set the working depth to 1/3 of the total working depth. • The lengthwise fitting position should lie over or behind the ploughing blade tip. -
Page 22: Feeler Wheels
FEELEr wHEELs Double feeler wheel • The working depth is set via the spindle (70) using the accompanying ratchet. Double feeler wheel fitted to the second last ploughing component. - 22 - (983) 9800-GB DOPPeLTAsTRAD... -
Page 23: Combi-Wheel (Feeler And Transport Wheel)
FEELER WHEEL COMBI-wheel (Feeler and transport wheel) working position As feeler wheel • The working depth is set using the spindle (1) If the adjustment range of the spindle is insufficient, the working depth can be additionally set using both adjusting screws (2). In both turning positions the varying working depths can also be levelled out with the screws (2). -
Page 24: Transport-Feeler Wheel
Changing to working position Tyres - SERVO PLUS only: Open hydraulic valve (F) - Raise plough using tractor’s lifting gear SERVO 45, SERVO 55 SERVO 35 - Release locks (for safety reasons do this from the tractor seat with the rope 10.0/75-12... -
Page 25: Offset Transport-Swivel Wheel
Feeler wheel Offset transport-swivel wheel Wheel variants 10.0/75-12 Diameter 705 mm Carrying capacity 1600 kg 13.3x55-16 Diameter 780 mm Carrying capacity 2050 kg Using as feeler wheel Using as transport wheel Fix the depth • Doing this relieves the tractor’s rear axle and lifting gear. -
Page 26: Changing To Transport Position
FEELEr wHEEL Changing to transport position 1. Adjust the plough in the smallest cutting width 6. Activate transport safeguard on attaching frame Safety warning! - via hydraulic cutting width adjustment with SERVO - With that swivel the control lever (on the attaching PLUS plough frame) 90°... -
Page 27: Changing To Working Position
FEELEr wHEEL Changing to working position 1. SERVO PLUS only: Open hydraulic valve (F) 7. Bring cylinder or damper into work position Safety warning! - Remove pin (7) 2. Lift the plough with the tractor’s lifting gear. Make sure that 3. -
Page 28: Plough-Trailing Implements
PLOUgH-TraiLing iMPLEMEnTs Optional equipment Extension arm with hydraulic releasing device for packer and trailing implements • A double-action control unit is necessary on the tractor. • The extension arm is fitted to the main frame. • A T screw fitting with a plug-in coupling sleeve is fitted to the return line (T) on the plough turning cylinder. Working position •... -
Page 29: Disconnect The Arm
PLOUgH-TraiLing iMPLEMEnTs Disconnect the arm 1. Disconnect the hydraulic pipe (Hyd) 2. Take away the two axles (B1, B2) 3. Take the arm from the bearings Adjusting the amortisation effect With the arm two springs are delivered (F1,F2) They reduce shocks wenn the trailing implement is penetrating Depending on the weight of the trailing implement it is necessary to chose the right spring... -
Page 30: Extension Arm With Hydraulic Releasing Device For Packer And Trailing Implements
A3 – distance approx. 60 cm > A1 this. A4 – distance approx. 90 cm > A1 A5 – greatest distance Optional extra for SERVO 25 S, SERVO 35 S, SERVO 45 S 115-07-04 - 0 - 0700_GB-scHweNkAUsLeGeR_983... -
Page 31: Working With A Trailing Implement
PLOUGH-TRAILING IMPLEMENTS Working with a trailing implement For attachment a latching device is fitted to the trailing implement which lies at right angles to the direction of travel. Working position Latching position 115-07-03 115-07-05 Engaging the trailing implement Ploughs without trailing implements •... - Page 32 PLOUGH-TRAILING IMPLEMENTS Detaching: 1. Disconnect hydraulic line 2. Detach draw spring (Z) 3. Remove bearing pin (B) 4. Remove extension arm (A) 115-07-01 Fitting to “PLUS” ploughs A control chain (S) is to be fitted on PLUS ploughs The latching position of the extension arm (A) is set with this control chain, depending on the chain length.
-
Page 33: Technical Data
TECHniCaL DaTa Vehicle Identification Plate • The implement’s exact designation and its fittings (frame height, A. Pöttinger Maschinenfabrik Ges. m. b. H. A-4710 Grieskirchen Oberösterreich component form, ...) are imprinted in the section „Type“. • The factory number is imprinted on the vehicle identification plate Modell (as shown opposite) and on the attachment frame. -
Page 34: Technical Data
0-5-40-45-50 cm 1704 kg 10 / 140 SERVO 45-N-402 102 cm 80 cm 2-8-4-48-54 cm 111 kg 88 / 120 servo 45 novA PLus Power requirement type Blades Component distance Frame height Cutting width Weight * from [kw/hp] SERVO 45-PN-495... -
Page 35: Technical Data
102 cm 80 cm 2-8-4-48-54 cm 1578 kg SERVO 45-S-N-502 5 (4+1) 102 cm 80 cm 2-8-4-48-54 cm 1800 kg servo 45 s novA PLus type Blades Component distance Frame height Cutting width Weight* SERVO 45-S-PN-495 95 cm 80 cm... -
Page 36: Optional Equipment
TECHniCaL DaTa Optional Equipment Trashboard Leg deflector Guiding plate Knife coulter Landside saver UW, UWS, W, WSS. U, UW, UWS, W, WSS. U, UW, UWS. U, UW, W, WSS. UW, UWS, W, WSS Maize mulcher Manure mulcher - skim coulter M1 / M2 Smooth disk coulter Cutaway disk coulter... -
Page 37: Equipments
EqUiPMEnTs Plough body forms Description • Easy to pull 1 UW 6 UW • Excellent clod breaking 9 UW • Suitable for all soils • Especially for slopes/shallow plougling 6 W • Easy to pull 5 W • Very good characteristics for newly 41 W ploughed fields The large slatted body... -
Page 38: Variation
VariaTiOn SERVO model SERVO PLUS model A standard plough variation Standard plough consisting of consisting of a. - a. Standard cutting width adjustment b. Four-bar lever 5 settings possible using screws b. Four-bar lever c. - d. Hydraulic cutting width adjustment - unlimited setting possible using hydraulic cylinder. -
Page 39: Supplement
sUPPLEMEnT GB-Anhang Titelblatt _BA-Allgemein... - Page 40 The original cannot be copied ... Things will run better with genuine Pöttinger parts • Quality and precise fitting The decision must be made, ”original” or ”imitation”? The decision is often governed by price and a ”cheap buy” can sometimes be very expensive. - Operating safety.
-
Page 41: Recommendations For Work Safety
Recommendations for work safety sUPPLEMEnT - a Recommendations for work safety 6.) Transport of persons prohibited All points refering to safety in this manual are indicated a. The transport of persons on the machine is not permitted. by this sign. b. -
Page 42: Combination Of Tractor And Mounted Implement
iMPOrTanT! aDDiTiOnaL inFOrMaTiOn Combination of tractor and mounted implement The mounting of implements on the front or rear three point linkage shall not result in exceeding the maximum permissible weight, the permissible axle loads and the tyre load carrying capacities ot the tractor. The front axle of the tractor must always to be loaded with at least 20 % of the unladen weight of the tractor. - Page 43 iMPOrTanT! aDDiTiOnaL inFOrMaTiOn 3. CALCuLAtIon oF tHe reAL Front AXLe LoAD t v tat (If with the front mounted implement (G ) the required minimum front ballasting (G ) cannot be reached, the weight of the front mounted V min implement has to be increased to the weight of the minimum ballasting at the front!) Record the calculated real front axle load and the permissible front axle load of the tractor into the table.
- Page 44 SERVO 45 S PLUS SERVO 45 NOVA SERVO 45 S NOVA SERVO 45 NOVA PLUS SERVO 45 S NOVA PLUS __________________________________________________________________________ (make, model) to which this certificate applies, conforms to the basic safety and health requirements of EEC Directions 98/37, (if applicable) and to the other relevant EEC Directions.
- Page 45 Im Zuge der technischen Weiterentwicklung La société PÖTTINGER Ges.m.b.H améliore Following the policy of the PÖTTINGER Ges. arbeitet die PÖTTINGER Ges.m.b.H ständig constamment ses produits grâce au progrès m.b.H to improve their products as technical an der Verbesserung ihrer Produkte. technique.
- Page 46 ALOIS PÖTTINGER Maschinenfabrik Gesellschaft m.b.H A-4710 Grieskirchen Telefon: 0043 (0) 72 48 600-0 Telefax: 0043 (0) 72 48 600-511 e-Mail: landtechnik@poettinger.co.at Internet: http://www.poettinger.co.at GEBR. PÖTTINGER GMBH Stützpunkt Nord Steinbecker Strasse 15 D-49509 Recke Telefon: (0 54 53) 91 14 - 0 Telefax: (0 54 53) 91 14 - 14 PÖTTINGER France 129 b, la Chapelle...
