Working Step
Connect 24 V
encoders
Incremental 24 V
encoder
24 V pulse encoder with-
out direction level (initia-
tor/BERO)
24 V pulse encoder with-
out direction level (initia-
tor/BERO)
24 V pulse encoder with
direction level
24 V pulse encoder with
direction level
Wiring digital inputs
and outputs
Digital inputs and outputs
Digital inputs and outputs
Connecting the auxil-
iary voltage and the
Encoder supply
load voltage
Supplying the digital in-
puts and outputs
FM 450-1 Counter Function Module
C79000-G7076-C450-01
www.gkbpx.com
Options/Procedure
Counter 2:
Terminal
26
28
23
24
25
Counter 1:
Terminal
14
16
11
Counter 2:
Terminal
26
28
23
Counter 1:
Terminal
14
16
11
12
Counter 2:
Terminal
26
28
23
24
Counter 1:
Terminal
29
30
31
33
34
Counter 2:
Terminal
41
42
43
45
46
Terminal
3
4
47
48
Starting Up the FM 450-1
Name
Function
1M
Encoder supply ground
24 VDC
24 V encoder supply
A*
Encoder signal A *
B*
Encoder signal B *
N*
Encoder signal N *
Name
Function
1M
Encoder supply ground
24 VDC
24 V encoder supply
A*
Encoder signal A *
Name
Function
1M
Encoder supply ground
24 VDC
24 V encoder supply
A*
Encoder signal A *
Name
Function
1M
Encoder supply ground
24 VDC
24 V encoder supply
A*
Encoder signal A *
B*
Direction level B*
Name
Function
1M
Encoder supply ground
24 VDC
24 V encoder supply
A*
Encoder signal A *
B*
Direction level B*
Name
Function
1I0
START digital input
1I1
STOP digital input
1I2
SET digital input
1Q0
Q0 digital output
1Q1
Q1 digital output
Name
Function
2I0
START digital input
2I1
STOP digital input
2I2
SET digital input
2Q0
Q0 digital output
2Q1
Q1 digital output
Name
Function
1L+
24 V auxiliary voltage
1M
Auxiliary voltage ground
2L+
24 V load voltage
2M
Load voltage ground
