Page 6
ASSEMBLY INSTRUCTIONS Step 1: Secure Front stabilizer (17) to Main frame (21) with Bolts (16), Arc washers (19) and Nuts (20).
Page 7
Step 2: A. Connect Sensor wire a (9) with Sensor wire c (12). Then connect Sensor wire b (10) with Sensor wire d (14).(See diagram a above) B. Connect Tension hook (13) with Tension control cable (11). (See diagram b above) C.
Page 8
Step 3: A. Connect Computer wire (1a) with Sensor wire a (9), then secure Computer (1) to Handlebar post (5) with Screws (42). Insert Sensor wire b (10) into the back of Computer (1). B. Secure Pedals (18L/R) onto the left and right crank of the Main frame (21). ★CAUTION: The left side of the machine has reversed threading.
Page 9
Step 4: A. Secure the Rear stabilizer (27) to the Rear main frame (25), with Bolts (16), Arc washers (19) and Nuts (20). B. Secure Backrest frame (39) to Rear main frame (25) with Screws (8), Spring washers (38) and Washers (32). ★Note: For easier installation of next step, try flipping Rear main frame (25) over.
Page 10
Step 5: A. Connect Sensor wire d (14) with Sensor wire 5 (24), then secure the Rear main frame (25) to the Main frame (21) with the Knob (22). ★CAUTION: There are different holes on the Rear main frame (25) which can be used for people with different height.
Page 11
Step 6: A. Secure Handle bar (34) to Backrest frame (39) with Bolts (37), Washers (32) and Nuts (31). B. Connect Sensor wire 5 (24) with Handle pulse wire (30). Installation is complete. Version: Jan.10th, 2014...
