330 Resistors
they do have a value marking on the top side. Make sure the
marking is facing up.
13
330 Resistors
0.1uF Capacitors
not polarized. They don't have a value marking. This means
they can be soldered into place in any rotation.
14
0.1uF Capacitors
Page 12
These resistors are not polarized. However,
Ceramic capacitors like these are
BOTTOM OF BOARD
Page 13
