SMD SOLDERING TIPS
Page
1
3
4
16
22
34
36
38
40
42
44
Don't:
Do:
Use the side of the tip of the iron, "The Sweet Spot."
Do:
Touch the iron to the component leg and metal SMD pad at
the same time.
Do:
While continuing to hold the iron in contact with the leg
and metal pad, feed solder into the joint.
Don't:
Glob the solder straight onto the iron and try to apply the
solder with the iron.
Do:
Use a sponge to clean your iron whenever black oxidization
builds up on the tip.
Use the very tip of the iron.
