QUICKSTART • LEVEL-1 SMD SOLDERING
Steps highlighted in yellow represent a polarized component.
Pay special attention to the component's markings indicating how
to place it on the board.
1
Locate the
Buzzer.
2
Locate the
Buzzer
position on the board.
BOTTOM OF BOARD
Page 4
3
[ STEPS 1 T0 8 ]
4
Touch iron's sweet spot to the start-pad for 2-3 seconds.
Pre-tin the start-pad by feeding solder into the joint.
Page 5
