FINAL ASSEMBLY

No screwdriver necessary.
Please only hand-tighten the screws and standoffs.
Button Pad
pad over LEDs.
35
Button Pad
Bezel (holds button pad) Attach to top. Lay bezel over button
pad, with notches for the screws pointing up.
36
Bezel
Standoffs and screws
through the bezel and button pad, then twist standoffs onto
the protruding screw. Hand tighten.
37
Screws x 4
AA Battery
and "-" indicators on the board. Turn on the board and verify
the LEDs are flashing.
38
AA Battery
Page 34
[ STEPS 35 T0 38 ]
(game control) Attach to top. Lay rubber button
(mechanical) Insert the screws
(power source) Insert the battery, following "+"
37
36
35
37
TOP SIDE VIEW
38
Page 35
