DRYER SUPPORT AND WASHER HARNESS PARTS
For Model: WGT3300SQ1
(Designer White)
Illus.
Part
No.
No.
DESCRIPTION
1 W10139637 Harness − Washer
1A
3350130 Plug, 3 Way
1B
3347243 Connector, 5 Way
1C
352089 Block,
Disconnect − Timer
1D
3350211 Receptacle, 3 Way
1E
62505 Block, Disconnect
2
3388851 Channel Assembly
(Left hand Side)
3
3388850 Channel Assembly
(Right Hand Side)
4
3390609 Shield, Harness
5
8545438 Hose, Pressure
Switch
6
8281256 Clip, Harness
7
343641 Screw, 10−16 x 1/2
8
63523 Protector, Harness
9
Terminal
94613 Male
94614 Female
10
3360056 Connector,
Pressure Switch
11
3400300 Bolt,
5/16−18 x 1/2
12
3393930 Nut, Hex (4)
13
3392232 Shield, Front
14
3390336 Shield,
Thermostat
15
3391249 Clip, Harness (2)
16
3354925 Connector,
H−Pod
8
W10143421
