Whirlpool WGT3300SQ1 Parts List page 6

Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, Roller
2 8066086 Plug,
Drum Hole
3 343641 Screw, 10−16 x 1/2
4 3392226 Clip, Thermostat
5 3392157 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 3391906 Seal, Lint Duct
8 3934666 Nut
9 3394984 Door, Lint
Screen
10 3389449 Baffle, Drum (3)
11 8563748 Pipe, Exhaust
12 3394986 Spring, Lint
Screen Door
13 3391685 Seal, Transition
Duct To Lint Duct
14 3357011 Screw, 10−16 x 1/2
15 3390647 Screw, 8−18 x 1/2
DRYER BULKHEAD PARTS
For Model: WGT3300SQ1
(Designer White)
Illus. Part
No. No.
16 W10001120 Nut, Hex (2)
17 3387809 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Tri− Ring
21 8536973 Support, Roller
22 3387230 Screw, 10−16 x 3/4
23 3394985 Housing, Outlet
24 3387910 Colar−Air Duct
25 3389448 Assembly, Drum
26 W10109200 Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 697557 Bulkhead, Front
29 8533971 Screw, 8−18 x 1/2
30 8299979 Grille, Outlet
31 697770 Seal, Cover Plate
32 3389644 Screen, Lint
33 8566209 Seal,
34 3403607 Thermal−Limiter
Illus.
DESCRIPTION No.
35
36
37
38
39
40
41
42
43
44
Transition Duct
45
6
Part
No. DESCRIPTION
3390935 Clip, Duct
Locator
3388909 Lint Duct
Assembly
(Includes Illus.
7 & 13 )
697772 Wheel, Blower
3389445 Duct, Transition
(Includes
Illus. 33)
697366 Plate, Blower
3388697 Fixed, Thermostat
(205 F)
694415 Clip, Strain
Relief
3387134 Thermostat,
Internal−Bias
695240 Screw, 8−18 x 1/2
8544363 Housing,
Blower
8571651 Bracket−Bulkhead
(Upper)
W10143421
