Size
Device
Brake chopper power electronics
1)
Response threshold [VDC]
2)
Peak braking power [kW]
software/hardware-side
Minimum ohmic resistance of an exter-
nally installed braking resistor
Continuous chopper power [kW]
1) Internal braking resistor (mounted on the base of the cooler) on request
2) Minimum switch-on time 250 µs
Table A.8 Brake chopper power electronics, BG7
NOTe.
The maximum overall capacitance of the multi-axis system DC link for a
ServoOne supply unit BG7 (incl.) must not exceed 25,000 μF.
BG7
SO84.375.S SO84.540.S
820
210/-
3.2 Ω
10
Operation Manual ServoOne Supply Unit
Size
Connection
Device
Screw size for ring cable lug
X11/ZK+, ZK-
Tightening torque
Screw size for ring cable lug
X11/PE 1)
Tightening torque
Screw size for ring cable lug
X12/L1, L2, L3
Tightening torque
Screw size for ring cable lug
X12/PE 1)
Tightening torque
Screw size for ring cable lug
X12/RB+, RB-
Tightening torque
1) The protective earth conductor cross-section depends on the cross-section of the phase conductor (see chap. 4.5, p. 40)
The minimum cross-section of the connection cables depends on the local regulations, conditions as well as on the rated
current of the supply unit.
Table A.9 Terminals, BG7
