LX90x
LX80x
and
GPS-Navigation System
Version 7.10
Revision 1
LXNAV d.o.o. • Kidričeva 24, 3000 Celje, Slovenia • tel +386 592 33 400 fax +386 599 33 522
info@lxnav.com
www.lxnav.com
•
